Toro TimeCutter SS 4200 - Product Overview; Component Identification

121-0771
1.Choke4.Slow
2.Fast
5.Powertake-off(PTO),Bladecontrolswitch
3.Continuousvariablesetting
ProductOverview
G014526
1
2
3
4
5
6
7
8
9
10
11
2
Figure4
1.Deector4.Heightofcutlever
7.Footrest10.Engine
2.Reardrivewheel
5.Operatorseat
8.Fueltankcap11.Frontcasterwheel
3.Motioncontrollevers
6.Smartspeedlever9.Controlpanel
11
