engine;theengineshouldnotcrank.Repeatwith
theothermotioncontrollever.
3.Whilesittingontheseat,movethebladecontrol
switchtoOff,andlockthemotioncontrolleversin
theparkposition.Starttheengine.Whiletheengine
isrunning,engagethebladecontrolswitch,andrise
slightlyfromtheseat;theengineshouldstop.
4.Whilesittingontheseat,movethebladecontrol
switchtoOff,andlockthemotioncontrollevers
intheparkposition.Starttheengine.Whilethe
engineisrunning,movethemotioncontrollevers
tothecenter,unlockedposition,engagetheblade
controlswitch,andriseslightlyfromtheseat;the
engineshouldstop.
StoppingtheEngine
1.Disengagethebladesbymovingthebladecontrol
switchtoOff(
Figure15).
2.MovethethrottlelevertoFast(
Figure13).
3.TurntheignitionkeytoOff(
Figure12)andremove
thekey.
Driving
Drivingthemachinebenetsfromanunderstandingof
whatzeroturnradiusmowermeans.Thedrivewheels
turnindependently,poweredbyhydraulicmotorson
eachaxle;henceonesidecanturninreversewhilethe
otherturnsforwardcausingthemachinetospinrather
turn.Thisvastlyimprovesthemachinemaneuverability
butmayrequiresomeadjustmentiftheoperatoris
unfamiliar.
WARNING
Themachinecanspinveryrapidly.Theoperator
maylosecontrolofthemachineandcausepersonal
injuryordamagetothemachine.
•Usecautionwhenmakingturns.
•Slowthemachinedownbeforemakingsharp
turns.
Thethrottlecontrolregulatestheenginespeedas
measuredinrpm(revolutionsperminute).Placingthe
throttlecontrolintheFastpositioncanbebestfor
performance.Formostapplications,operatinginthe
fullthrottlepositionisdesirable.
Figure16
1.Park(brake)position
3.Forward
2.Centerunlockposition
4.Backward
UsingtheSmartSpeed™Control
System
TheSmartSpeed™ControlSystemlever,located
belowtheoperatingposition(
Figure17),givesthe
operatorachoicetodrivethemachineattwoground
speedranges,highandlow .
G014475
1
Figure17
1.Smartspeedlever
Tochangespeeds:
18
