Assemblingthe
Wheel-LoadingKit
Note:Performthefollowingstepstoassemblethe
left-andright-sidedwheelramps.Thefollowing
illustrationsshowtherightsideofthewheel-loading
kit.
1.Use4torx-headscrewsand4nuts(5/16inch)
tosecurethelatch-pinbrackettotheguideplate
ontherampassembly(Figure9).
g345943
Figure9
Rightsideshown.
1.Torx-headscrew3.Latch-pinbracket
2.Nut(5/16inch)
2.Use10bolts(5/16x3/4inch)and10nylock
nuts(5/16inch)tosecuretheguideplatetothe
rampassembly(Figure10).
Theguideplatesmustbeinstalledwiththelatch
pinsfacingtheoutside.RefertoFigure30in
LoadingtheTrailer(page12)foranillustration
ofproperlyinstalledguideplates.
g345954
Figure10
1.Guideplate3.Nylocknut(5/16inch)
2.Bolt(5/16x3/4inch)
3.Useanut(1/4inch)toinstallabumpertothe
rampassembly(Figure11).
g340443
Figure11
1.Bumper
2.Nut(1/4inch)
4.Useaagpinandahex-headscrewtosecure
thewheelstoptotherampassembly(Figure12).
