Toro Z Master Z253 Service Manual

HYDRAULIC SYSTEMS
4 - 6 Mid-Mount Z Service Manual
8. Remove the front two wheel motor mounting bolts
and swing the brake linkage out of the way (Figure
70).
9. Remove the rear two wheel motor mounting bolts
and then remove the wheel motor from the
chassis (Figure 70).
Figure 70

Toro Z Master Z253 Specifications

General

Brand	Toro
Model	Z Master Z253
Category	Lawn Mower
Language	English
