10. LEVEL CONTROL INPUTS
●
Additional level probe for isolated tank
●
Not used
●
2 Probes
●
1 Level probe + Restart time
If the tank is made of insulating material, an
additional probe must be added to the bottom
connected to PE.
When the level control
is not used, PE and
2 terminals must be
bypassed
PE 1 2 3 4
2 Sondas
ON
OFF
OK
PE 1 2 3 4
2 Sondas
ON
OFF
OK
PE 1 2 3 4
ON
OFF
OK
PE 1 2 3 4
1 Sondas + Tiempo de rearme
OFF
ON
OFF / Imin
PE 1 2 3 4
PE 1 2 3 4
