ENGLISH ( EN )
40
21. TECHNICAL CHARACTERISTICS
Vigilec Mono (V1M) Vigilec Mini (V1N)
Power suply 230 VAC 230/400 VAC (selectable)
Admissible voltage variation +/-20% (>30%: Auto Power Off) +/-20% (>30%: Auto Power Off)
Max. current 18 Amp AC3 16 Amp AC3
Protections
Overload, Underload, Excessive
frequency of starts,
Anti-blocking.
Overload, Underload, Phase-loss,
Excessive frecuency of starts,
Anti-blocking.
Display LED 4 digits LED 4 digits
Signaling Pump ON, Alarm, Low level,
Max. current (I.max), Min.
current (I.min), Restart time and
ow switch inhibition.
Pump ON, Alarm, Low level,
Max. current (I.max), Min.
current (I.min), Restart time
and ow switch inhibition.
Overload setting (I.max) 0.6 - 20.0 Amp 0.6 - 20.0 A
Underload setting (I.min) OFF- 0.5 –19.8 Amp OFF - 0.5 - 19.8 A
Restart time setting from 3 minutes to 99 hours or
manual
from 3 minutes to 99 hours or
manual
Inhibition time setting 5-200 seconds (ow switch) 5-200 seconds (ow switch)
Overload trip time 7 seconds 7 seconds
Underload trip time 4 seconds (20 sec. at startup) 4 seconds (20 sec. at startup)
Capacitor maximum capacity 80uF (50uF inside the unit) -
Probes operating voltage 24 VAC 24 VAC
Probes sensitivity 10 K ± 15% Ω 10 K ± 15% Ω
External input ON/OFF Voltage or contact from 6 to
400 VAC/VDC
Voltage or contact from 6 to
400 VAC/VDC
Alarm and auxiliar output
contact
AC1: 2 A/250 VAC
AC11: 1 A/230 VAC
AC1: 2 A/250 VAC
AC11: 1 A/230 VAC
Recorded information Running hours, number of
starts, number of alarms and
last alarm current.
Running hours, number of
starts, number of alarms and
last alarm current.
Control terminal blocks 4 mm
2
4 mm
2
Mounting method Mounting brackets or direct to
wall
Mounting brackets or direct to
wall
Cable glands
(Power/Motor/Control)
1xM20/1xM20/2xM16 1xM20/1xM20/1xM20+2xM16
Working temperature -10 +55ºC -10 +55ºC
Protection degree IP56 IP56
Size 185 x 200 x 95 mm 225 x 255 x 110 mm
Net weight 950 g 1,8 Kg
Software version V.1.4 V.1.4
