User’s Manual 2-1
Chapter 2
The Grand Tour
This chapter identifies the various components of your computer. Become
familiar with each component before you operate the computer.
Front with the display closed
The figure below shows the computer’s front with its display panel in the
closed position.
Front of the computer with display closed
An asterisk * indicates a optional feature that is dependant on the model
purchased.
Display latch
Volume control
Headphone
Microphone
Multiple Digital
Media card
indicator
Multiple Digital Media card slot *
System Indicators
Infrared port *
Display latch This latch secures the LCD panel in its closed position.
Slide the latch to open the display.
Volume control Use this dial to adjust the volume of the system speaker
and headphones.
