User’s Manual 2-4
The Grand Tour
Right side
The figure below shows the computer’s right side.
The right side of the computer
Optical Media DriveUSB Ports
Modem jackWireless Communication Switch
Security Lock Slot
Security lock
slot
A security cable attaches to this slot. The optional
security cable anchors your computer to a desk or other
large object to deter theft.
Universal
Serial Bus
Ports
The two Universal Serial Bus (USB) ports comply with
USB Serial 2.0 standards, which enables data transfer
speeds 40 times faster than the USB 1.1 standards.
(The ports also support USB 1.1)
Keep foreign objects out of the USB connectors. A pin or similar object can
damage the computer’s circuitry.
Operation of all functions of all USB devices has not been confirmed.
Some functions might not execute properly.
Optical Media
Drive
A DVD-ROM drive, CD-RW/DVD-ROM drive, DVD
Super Multi (+-R Double Layer) drive.
Modem jack The modem jack lets you use a modular cable to
connect the modem directly to a telephone line.
Wireless com-
munication
switch
Slide this switch to the right (toward the back of the
computer) to turn on Wireless communication. Slide it to
the left (toward the front of the computer) to turn off the
functions. (Provided with some models)
Set the switch to off in airplanes and hospitals. Check the Wireless
communication indicator. It will stop glowing when the wireless
communication is disconnected.
