User’s Manual 4-3
Operating Basics
Replacing the Cap
The AccuPoint cap is an expendable item that should be replaced after
prolonged use
1. To remove the AccuPoint cap, firmly grasp the cap and pull it straight up.
Removing the AccuPoint cap
2. Position a new cap on the peg and press it into place.
Using the USB diskette drive
A 3 1/2" diskette drive connects to the computer’s USB port.
It accommodates 1.44-megabyte or 720-kilobyte diskettes.
Refer to Chapter 2, The Grand Tour, for more information.
Connecting 3 1/2" diskette drive
To connect the drive, plug the diskette drive connector into a USB port.
Refer to the figure below.
PEG
Touch Pad
The peg is square, so be careful to align the cap's square hole with the
peg.
Make sure the connector is right side up and properly aligned with the
socket. Do not try to force the connection, doing so can damage the
connecting pins.
