E-5
8. Place the media between the Media Guides, adjust the Media Guides to the media width, and
tighten the Locking Screw.
9. Check that the media path through the printer is straight. The media should be centered under
the Print Head.
10. Lower the Print Head Block until it stops.
Batch mode
In the batch mode, the media is continuously printed and fed until the number of labels/tags
specified in the issue command have been printed.
In the case of labels rolled with
the print side facing inside.
In the case of labels rolled with
the print side facing outside.
Guide Shaft
Media
Media Guide
Supply Holder
Media Guide
Print Head
Locking Screw
Media
To Next Page
