BFV700BLTHQMR
‐44‐
6.6Interfaces
ThissectionprovidesinformationaboutIOportspecificationsfortheprinter.
6.6.1 USB
TherearetwocommonUSBconnectors.Typically,typeA isfoundonhostsandhubs;typeBisfoundon
devicesandhubs.Thefigurebelowshowstheirpinouts.
TypeA TypeB
Pin Signal Description
1 VBUS +5V
2 D‐ Differentialdatasignalingpair‐
3 D+ Differentialdatasignalingpair+
4 Ground Ground
