User’s Manual EN-45
Specifications
Specifications
This section summarizes the dynadock’s technical specifications.
Physical Dimensions
Environmental Requirements
Power Requirements
Weight 507g/17.8 ounces (including the Base)
Size 45(w) x 78(d) x 210(h) mm/1.8" (w) x 3.1" (d) x 8.27" (h)
(not including the parts that extend beyond the main body)
114(w) x 130(d) x 223(h) mm/4.5" (w) x 5.2" (d) x 8.8" (h)
(including the Base)
Conditions Ambient temperature Relative
humidity
Operating 5°C to 35°C (41°F to 95°F) 20% to 80%
Non-operating -20°C to 65°C (-4°F to 149°F) 10% to 90%
Thermal Gradient 20°C per hour maximum
Wet-bulb
Temperature
26°C maximum
AC adaptor Input: AC 100-240V
Output: DC 5V / 5A
