42
Remote Controller Schedule Timer
On an ESTIA site the customer requires the hot water function to be ON between the hours of 01:00
and 06:00. The customer requires the set point for the domestic hot water to be set to 65°C
For space heating the customer requires the ESTIA to run in heating mode for the following periods:
Period 1: 07:00 ~ 10:00
Period 2: 15:00 ~ 22:00
The customer is using radiators as the heating emitters and requires the water set point temperature
to be set to 50°C. The schedule timer must be set the same for all days of the week.
For each day the timer function will be set as shown below:
STEP No.
Time
Function
STEP 1
01:00
DHW ON, DHW set point = 65°C
STEP 2
06:00
DHW OFF
STEP 3
07:00
Zone 1 ON, heating mode, water set point = 50°C
STEP 4
10:00
Zone 1 OFF
STEP 5
15:00
Zone 1 ON, heating mode, water set point = 50°C
STEP 6
22:00
Zone 1 OFF
Schedule Timer Set Up
1. Access remote controller (RC) timer function press the SCHEDULE button for a minimum of 4
seconds. Check the RC display changes to show the schedule timer display
2. Select the required day for the schedule timer press the DAY button until the symbol is
displayed above the required day. Press the SET button to accept the command
3. Set up the required timer steps for the selected day press the STEP button until STEP 1 is
displayed on the RC:
Press the STEP button > check STEP 1 is displayed on the RC
Press the SET button
Press the TIME ▼▲buttons to set 01:00 on the time display of the RC
Press the HOT WATER button to set the hot water function ON > check that a
numerical temperature is displayed on the RC for the hot water function
Press the TEMPERATURE ▼▲ buttons to set the 65°C hot water set point
Press the SET button
Press the STEP button > check STEP 2 is displayed on the RC
Press the SET button
Press the TIME ▼▲buttons to set 06:00 on the time display of the RC
Press the HOT WATER button to set the hot water function to OFF > check that the
RC display changes to - - - - for the hot water function
Press the SET button
Press the STEP button > check STEP 3 is displayed on the RC
Press the TIME ▼▲buttons to set 07:00 on the time display of the RC
Press the ZONE1, 2 button to set the space heating function ON > check that a
numerical temperature is displayed on the RC for the zone 1 function
Press the OPERATING MODE button > check that the heating mode symbol is
displayed on the RC
Press the TEMPERATURE ▼▲ buttons to set the 50°C zone 1 set point
Press the SET button
Press the STEP button > check STEP 4 is displayed on the RC
Press the SET button
Press the TIME ▼▲buttons to set 10:00 on the time display of the RC
Press the ZONE1, 2 button to set the space heating function OFF > check that the
RC display changes to - - - - for zone 1
Press the SET button
Press the STEP button > check STEP 5 is displayed on the RC
Press the SET button
