4.5 HDD 4 Replacement Procedures
4.5 HDD
CAUTION: When handling the HDD, do not press the top surface as shown by the arrow.
Hold it by the sides.
Removing the HDD
To remove the HDD, follow the steps below and refer to Figure 4-5 to 4-7.
1. Turn the computer upside down.
2. Loosen the screw (with an e-ring) and remove the HDD cover while releasing latches.
HDD cover
Screw (e-ring)
Figure 4-5 Removing the HDD cover
TECRA M5 Maintenance Manual (960-542) [CONFIDENTIAL] 4-13
