4 Replacement Procedures 4.28 Hinge
4.28 Hinge
Removing the Hinge
To remove the hinge, follow the steps below and refer to Figure 4-50-a to 4-53.
1. Remove the LCD cable holder A while releasing the latch.
LCD cable holder A
Latches
Figure 4-50-a Removing the LCD cable holder
4-72 [CONFIDENTIAL] TECRA M5 Maintenance Manual (960-542)
