4 Replacement Procedures 4.27 Bluetooth module
4.27 Bluetooth module
Removing the Bluetooth module
To remove the Bluetooth module, follow the steps below and refer to Figure 4-49.
CAUTION: Do not try to remove the Bluetooth module with the computer turned on.
You can damage the computer or Bluetooth module. Do not touch the
connectors on the Bluetooth module on the computer. Debris on the
connectors may cause Bluetooth access problems.
1. Disconnect the Bluetooth antenna cable from the Bluetooth module using an
antenna coaxial cable disconnector.
2. Remove the Bluetooth module from the slot.
3. Disconnect the Bluetooth cable from the connector on the Bluetooth module.
Bluetooth module
Bluetooth antenna cable
Bluetooth cable
Figure4-49 Removing the Bluetooth module
4-70 [CONFIDENTIAL] TECRA M5 Maintenance Manual (960-542)
