Toshiba M5 Maintenance Manual

4.25 Touch pad 4 Replacement Procedures
TECRA M5 Maintenance Manual (960-542) [CONFIDENTIAL] 4-67
Installing the Touch pad
To install the touch pad, follow the steps below and refer to Figure 4-47.
1. Connect the touch pad cable to the connector on the touch pad and stick the glass
tape.
2. Install the touch pad assembly to the slot.
3. Install touch pad cover while engaging the latches.
4. Secure the touch pad assembly with the following screws.
• M2.5×4B FLAT HEAD screw ×2

Toshiba M5 Specifications

General

Screen Size	14.1 inches
Battery Life	Up to 4 hours
Optical Drive	DVD
Networking	Wi-Fi 802.11a/g
Ports	3 USB 2.0, VGA
