– 295 –
Ref.
No.
Part No. Description
Q'ty/Set MMY-
MAP0804
HT8P
MAP1004
HT8P
MAP1204
HT8P
MAP1404
HT8P
MAP1604
HT8P
001 43T20333 FAN, PROPELLER 1 1 1 1 1
002 43T19354 CABINET, AIR OUTLET 1 1 1 1 1
003 43T00624 CABINET ASSY, AIR INLET, FRONT 1 1 1
004 43T00620 CABINET, AIR INLET, BACK 1 1 1
005 43T00625 CABINET ASSY, AIR INLET, FRONT 1 1
006 43T00622 CABINET, AIR INLET, BACK 1 1
007 43T41453 COMPRESSOR, DA421A3FB-29M 2 2 2 3 3
008 43T63345 SWITCH, PRESSURE 2 2 2 3 3
009 43T57303 HEATER, CASE, 29W 240V 2 2 2 3 3
010 43T57304 HEATER, CASE, 55W 240V 1 1 1 1 1
011 43T20336 MOTOR ASSY, FAN, DC280V 1 1 1 1 1
012 43T46381 VALVE, BALL, SBV-JA5GTC-1 1 1
013 43T46366 VALVE, PACKED, 9.52 1 1 1 1 1
014 43T46374 VALVE, PACKED, 12.7 1 1 1
015 43T46393 VALVE, BALL, 25.4 1 1 1 1 1
016 43T46403 COIL, SOLENOID, AC220V-240 50HZ 1 1 1 3 3
017 43T46401 COIL, SOLENOID 1 1 1 1 1
018 43T46408 VALVE, 2WAY 5 5 5 5 5
019 43T46407 COIL, PMV 2 2 2 3 3
020 43T46410 VALVE, 2WAY 2 2
021 43T46411 VALVE, 2WAY 1 1 1 1 1
022 43T46397 VALVE, 4WAY 1 1 1 1 1
023 43T46395 VALVE, CHECK 1 1 1 1 1
024 43T46396 VALVE, CHECK 1 1
025 43T46394 VALVE, PMV 2 2 2 3 3
026 43T46412 VALVE, 2WAY 3 3 3 3 3
027 43T46405 COIL, VALVE, 2WAY 8 8 8 8 8
028 43T48306 SEPARATOR 1 1 1
029 43T48307 SEPARATOR 1 1
030 43T48308 TANK, LIQUID 1 1 1
031 43T48309 TANK, LIQUID 1 1
032 43T48305 ACCUMULATOR 1 1 1 1 1
036 43T43478 CONDENSER ASSY, THREE ROW, LEFT 1 1 1
037 43T43479 CONDENSER ASSY, THREE ROW, RIGHT 1 1 1
038 43T43480 CONDENSER ASSY, THREE ROW, LEFT 1 1
039 43T43481 CONDENSER ASSY, THREE ROW, RIGHT 1 1
040 43T46398 VALVE, CHECK 2 2 2 3 3
041 43T46399 VALVE, CHECK 1 1 1 1 1
042 43T46400 VALVE, CHECK 3 3 3 4 4
043 43T46409 JOINT, CHECK 3 3 3 3 3
044 43T49348 RUBBER, SUPPORTER, PIPE 1 1 1 1 1
045 43T49349 RUBBER, SUPPORTER, PIPE 1 1 1 2 2
046 43T49350 RUBBER, SUPPORTER, PIPE 3 3 3 5 5
047 43T49351 RUBBER, SUPPORTER, PIPE 1 1 1 4 4
035 GUARD, FAN 1 1 1 1 1
43T19353
43T19359
∗1
∗1 For -E, -TR model
To Next Page
