Toshiba PORTEGE R700 Series Maintenance Manual

Troubleshooting Procedures
2.17 Fingerprint sensor Troubleshooting
CAUTION: To delete the account for confirming the fingerprint operation, it is necessary
to log on by the account with the management authority. If the password has
been set to log on, ask the Log-ON password to the user.
To check if the Fingerprint sensor works correctly or not, follow the troubleshooting
procedures below as instructed.
When failed in Procedure 1 to Procedure 3, execute Procedure 4.
Procedure 1: Setting Windows Log-ON password
Procedure 2: Registration of fingerprint
Procedure 3: Authentication of fingerprint
Procedure 4: Connector Check and Replacement Check
CAUTION: Scan your finger shown below.
1. Lay your finger straight to the sensor and put lightly the first joint of your
finger at the centerline of the fingerprint sensor.
2. Slide slowly your finger from the first joint to fingertip at constant speed.
When not recognized, adjust the speed.
Fingerprint
sensor
Fingerprint
sensor
PORTÉGÉ R700 Series Maintenance Manual (960-833) [CONFIDENTIAL] 2-57

Toshiba PORTEGE R700 Series Specifications

General

Processor	Intel Core i5 or i7
Display Size	13.3 inches
Resolution	1366 x 768
RAM	Up to 8GB DDR3
Graphics	Intel HD Graphics
Operating System	Windows 7 Professional
Optical Drive	DVD SuperMulti Drive
Bluetooth	Bluetooth 2.1 + EDR
Card Reader	SD Card Reader
Webcam	Integrated Webcam
Storage	HDD or SSD options available
Wireless	Wi-Fi 802.11 a/g/n
Ports	USB 2.0, VGA, HDMI, Ethernet
Weight	Approximately 1.4 kg (3.1 lbs)
Battery Life	Up to 8 hours (depending on configuration and usage)
