Toshiba PORTEGE R700 Series Maintenance Manual

Appendices Appendix C Pin Assignments
C-26 [CONFIDENTIAL] PORTÉGÉ R700 Series Maintenance Manual (960-833)
Finger sensor board (FULFS*)
C.29 CN3650 System board interface connector (6-pin)
Table C- 29 System board interface connector (6-pin)
Pin No. Signal Name Pin No. Signal Name
1 A-E3V 2 FGSPON-S3N
3 GND 4 ZUSBFS-E3N
5 ZUSBFS-E3P 6 GND
1T GND 2T GND

Toshiba PORTEGE R700 Series Specifications

General

Processor	Intel Core i5 or i7
Display Size	13.3 inches
Resolution	1366 x 768
RAM	Up to 8GB DDR3
Graphics	Intel HD Graphics
Operating System	Windows 7 Professional
Optical Drive	DVD SuperMulti Drive
Bluetooth	Bluetooth 2.1 + EDR
Card Reader	SD Card Reader
Webcam	Integrated Webcam
Storage	HDD or SSD options available
Wireless	Wi-Fi 802.11 a/g/n
Ports	USB 2.0, VGA, HDMI, Ethernet
Weight	Approximately 1.4 kg (3.1 lbs)
Battery Life	Up to 8 hours (depending on configuration and usage)
