Toshiba PORTEGE R700 Series Maintenance Manual

Appendices Appendix C Pin Assignments
C-12 [CONFIDENTIAL] PORTÉGÉ R700 Series Maintenance Manual (960-833)
C.6 CN2520 EXPRESS CARD interface connector (40-pin)
Table C- 6 EXPRESS CARD interface connector (40-pin)
Pin No. Signal Name Pin No. Signal Name
1 GND 2 GND
3 GND 4 GND
5 ZETCRD-P1P 6 ZETCRD-P1N
7 GND 8 GND
9 GND 10 GND
11 ZERCRD-P1P 12 ZERCRD-P1N
13 GND 14 GND
15 GND 16 GND
17 XPECRD-P0P 18 XPECRD-P0N
19 NC 20 CPPE-E3N
21 CRDCRQ-E3N 22 CRD-P3V
23 CRD-P3V 24 CRD-P3V
25 CRDRST-E3N 26 CRD-E3V
27 PEWAKE-E3N 28 CRD1R5-P1V
29 CRD1R5-P1V 30 CRD-E3V
31 CRD-E3V 32 NC
33 NC 34 CPUSB-E3N
35 ZUSBEX-E3P 36 ZUSBEX-E3N
37 GND 38 GND
39 GND 40 GND
1T GND 2T GND

Toshiba PORTEGE R700 Series Specifications

General

Processor	Intel Core i5 or i7
Display Size	13.3 inches
Resolution	1366 x 768
RAM	Up to 8GB DDR3
Graphics	Intel HD Graphics
Operating System	Windows 7 Professional
Optical Drive	DVD SuperMulti Drive
Bluetooth	Bluetooth 2.1 + EDR
Card Reader	SD Card Reader
Webcam	Integrated Webcam
Storage	HDD or SSD options available
Wireless	Wi-Fi 802.11 a/g/n
Ports	USB 2.0, VGA, HDMI, Ethernet
Weight	Approximately 1.4 kg (3.1 lbs)
Battery Life	Up to 8 hours (depending on configuration and usage)
