Toshiba PORTEGE R700 Series Maintenance Manual

Appendix C Pin Assignments Appendices
PORTÉGÉ R700 Series Maintenance Manual (960-833) [CONFIDENTIAL] C-31
C.39 CN2610 PCI-E Mini(3G) CARD interface connector (52-pin)
Table C- 39 PCI-E Mini(3G) CARD interface connector (52-pin)
Pin No. Signal Name Pin No. Signal Name
1 NC 2 E3V
3 NC 4 GND
5 NC 6 NC
7 NC 8 UIMPWR-E3V
9 GND 10 UIMDAT-E3P
11 NC 12 UIMCLK-E3P
13 NC 14 UIMRST-E3P
15 GND 16 NC
17 NC 18 GND
19 NC 20 3GRFON-S3N
21 GND 22 NC
23 NC 24 E3V
25 NC 26 MINDET-P3N
27 GND 28 NC
29 GND 30 NC
31 NC 32 NC
33 NC 34 GND
35 GND 36 ZUSB3G-E3N
37 GND 38 ZUSB3G-E3P
39 E3V 40 GND
41 E3V 42 3GLED-E3P
43 GND 44 NC
45 NC 46 NC
47 NC 48 NC
49 NC 50 GND
51 NC 52 E3V
1T
GND
2T
GND

Toshiba PORTEGE R700 Series Specifications

General

Processor	Intel Core i5 or i7
Display Size	13.3 inches
Resolution	1366 x 768
RAM	Up to 8GB DDR3
Graphics	Intel HD Graphics
Operating System	Windows 7 Professional
Optical Drive	DVD SuperMulti Drive
Bluetooth	Bluetooth 2.1 + EDR
Card Reader	SD Card Reader
Webcam	Integrated Webcam
Storage	HDD or SSD options available
Wireless	Wi-Fi 802.11 a/g/n
Ports	USB 2.0, VGA, HDMI, Ethernet
Weight	Approximately 1.4 kg (3.1 lbs)
Battery Life	Up to 8 hours (depending on configuration and usage)
