9-1-1. Installation Diagram of Indoor and Outdoor Units
As shown in the figure, hang power cord
and connecting cable downward, and
take out it along piping connection port.
Saddle
Extension
drain hose
(Option:
RB–821SW)
100 mm or
more from wall
600 mm or more
50 mm or more
from wall
250 mm
or
more from
wall
200 mm or more
For the rear left and left
piping
Insert the cushion between
the indoor unit and wall,
and tilt the indoor unit for
better operation.
Wall
Do not allow the drain hose
to get slack.
Make sure to run the drain
hose sloped downward.
Cut the piping hole
sloped slightly
Shield
pipe
A
ir
f
ilt
e
r
H
o
o
k
Hook
(A
tta
c
h
to
th
e
fr
o
n
t p
a
n
e
l.)
65 mm or more
170 m
m
or m
ore
1 Installation
plate
170 mm or more
5 Sasa-Zeolite
plus filter
6Bio-enzyme &
The auxiliary piping can be
connected the left, rear left,
rear right, right, bottom right
or bottom left.
Right
Rear right
Bottom right
Left
Rear left
Bottom left
Gingko filte
2
Wireless remote
control
8
Pan head wood screw
4
Remote control holder
Insulate the refrigerant
pipes separately with
insulation, not together.
6 mm thick heat resisting
polyethylene foam
Before installing the
wireless remote control
• With the remote control cover
open, load the batteries supplied
correctly, observing their
polarity.
22
22
2 Wireless remote control
Cover
33
33
3 Batteries
FILE NO. SVM-05026
