BOARD AFV BOARD ATA
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
P5 A,B P000483720 1VSA15656 BOARD AFV
P5 C P000484120 1VSA15657 BOARD AFV
Consists of the following:
CAPACITORS
C1 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C4 CHD1JJ3CH560 CHIP CERAMIC CAP. CH J
56pF/50V
C5 CHD1JJ3CH220 CHIP CERAMIC
CAP.(1608) CH J 22pF/50V
C6 CHD1JJ3CH560 CHIP CERAMIC CAP. CH J
56pF/50V
C7 CHD1JC3CH3R0 CHIP CERAMIC CAP. CH
C 3pF/50V
C8 CHD1JC3CH3R0 CHIP CERAMIC CAP. CH
C 3pF/50V
C11 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C12 CE1CMASSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C13 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C14 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C15 CE1CMASSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C16 CE1CMASSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C17 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C19 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C20 CE1JMASSL3R3 ELECTROLYTIC CAP.
3.3μF/50V M H7
C21 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C22 CE1CMASSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C23 C CHD1AZ30F474 CHIP CERAMIC CAP. F Z
0.47μF/10V
C24 CE1JMASSLR22 ELECTROLYTIC CAP.
0.22μF/50V M H7
C27 CCA1JZTFZ104 CERAMIC CAP.(AX) F Z
0.1μF/50V
CONNECTOR
CN1 JTED009ER045 ANGLE PIN HEADER 9P
IMSA-6029B-1-09Z003-
DIODE
D2 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
IC
IC1 P000459920 NSZBA0SP3005 IC AUDIO PROCESSOR
MSP3417G-QG-B8-V3
COILS
L1 LLARKBSTU100 INDUCTOR 10μF-K-5FT
L2 JW5.0T BOARD JUMPER D0.6-
P5.0
L3 LLAXKATTU180 INDUCTOR 18μF-K-26T
L4 LLARKBSTU100 INDUCTOR 10μF-K-5FT
RESISTORS
R1 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R2 C RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R4 RRXAJR5Z0124 CHIP RES. 1/10W J 120k
Ω
R5 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R6 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R7 C RRXAJR5Z0122 CHIP RES. 1/10W J 1.2k Ω
MISCELLANEOUS
X1 P000468230 FXD186LLN001 XTAL 18.432MHz
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
P6 P000472730 1VSA13582 BOARD ATA
Consists of the following:
CONNECTORS
CN3001 JCYKC40JC002 IDC SOCKET 40PIN VT
YKF43-0025
CN3002 JCFHD40HQ007 FPC/FFC
CONNECTOR(40PIN)
FH12-40S-0.5SH(89)
