20070312 1-21-15 E3B90EL
BOARD SWITCH
BOARD REAR JACK
SW3004 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW3005 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW3006 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW3007 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
MISCELLANEOUS
B-9A 0VM409508 BUSH LED(F) H3700UD
B-9B 0VM409508 BUSH LED(F) H3700UD
B-9C 0VM409508 BUSH LED(F) H3700UD
B-9D 0VM409508 BUSH LED(F) H3700UD
B-9E 0VM409508 BUSH LED(F) H3700UD
JK3001 P000457110 JXRL010LY135 JACK RCA(YELLOW)
MTJ-032-05B-20(B110)
JK3002 P000457120 JXRL010LY136 JACK RCA(WHITE) MTJ-
032-05B-22(B110)
JK3003 P000457090 JYRL010LY029 JACK RCA(RED) MTJ-
032-05A-21(B110)
JK3004 P000457080 JXEL040RP003 MINI DIN SOCKET MDC1-
34-020
W7 P000483970 WX1E3B00-007 PARALLEL WIRE 5P
AWG26#2651/120MM
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
P3-1 A,C P000483730 1VSA15686-1 BOARD SWITCH (PW/
SW-C)
P3-1 B P000484020 1VSA15561-1 BOARD SWITCH (PW/
SW-C)
Consists of the following:
DIODE
D3007
NPQZ1CHJGTNN
LED(GREEN)
LTL1CHJGTNN
RESISTOR
R3021 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
SWITCHES
SW3008 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW3009 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW3010 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
MISCELLANEOUS
B-9F 0VM409508 BUSH LED(F) H3700UD
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
P3-3 A,C P000483750 1VSA15686-3 BOARD REAR JACK (PW/
SW-D)
P3-3 B P000484040 1VSA15561-3 BOARD REAR JACK (PW/
SW-D)
Consists of the following:
CAPACITORS
C2001 CE1CMASDL101 ELECTROLYTIC CAP.
100μF/16V M
C2002 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
C2003 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C2004 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C2005 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C2006 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C2007 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C2008 CHD1JK30B102 CHIP CERAMIC
CAP.(1608) B K 1000pF/
50V
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
C2009 CE1JMASDL1R0 ELECTROLYTIC CAP. 1μF/
50V M
C2010 CE1JMASDL1R0 ELECTROLYTIC CAP. 1μF/
50V M
C2011 CHD1JK30B102 CHIP CERAMIC
CAP.(1608) B K 1000pF/
50V
C2012 CE1JMASDL1R0 ELECTROLYTIC CAP. 1μF/
50V M
C2013 CHD1JK30B102 CHIP CERAMIC
CAP.(1608) B K 1000pF/
50V
DIODES
D2001 QDTA00MTZJ11 ZENER DIODE MTZJT-
7711A
D2002 QDTA00MTZJ11 ZENER DIODE MTZJT-
7711A
D2003 QDTA00MTZJ11 ZENER DIODE MTZJT-
7711A
D2004 QDTA00MTZJ11 ZENER DIODE MTZJT-
7711A
D2005 QDTA00MTZJ11 ZENER DIODE MTZJT-
7711A
D2006 QDTA00MTZJ11 ZENER DIODE MTZJT-
7711A
D2007 QDTA00MTZJ11 ZENER DIODE MTZJT-
7711A
D2008 QDTA00MTZJ11 ZENER DIODE MTZJT-
7711A
D2009 QDTA00MTZJ11 ZENER DIODE MTZJT-
7711A
D2010 QDTA00MTZJ11 ZENER DIODE MTZJT-
7711A
COILS
L2003 ---------- BEAD CORE
ASSEMBLYE3B91BD
L2003-1 JW35.0T BOARD JUMPER D0.6-
P35.0
L2003-2 XL03010XM001 BEAD CORE B16 RH
3.5X10X1.3
TRANSISTORS
Q2001 NQS4KTA1266P TRANSISTOR KTA-1266-
GR-AT/P
Q2002 NQSYKTC3199P TRANSISTOR KTC3199-Y-
AT / P
Q2003 NQSYKTC3199P TRANSISTOR KTC3199-Y-
AT / P
RESISTORS
R2001 RCX6JATZ0681 CARBON RES. 1/6W J 680
Ω
R2002 RRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R2003 RCX4JATZ0750 CARBON RES. 1/4W J 75
Ω
R2005 RCX4JATZ0821 CARBON RES. 1/4W J 820
Ω
R2006 RCX4JATZ0221 CARBON RES. 1/4W J 220
Ω
R2007 RCX4JATZ0821 CARBON RES. 1/4W J 820
Ω
R2008 RCX4JATZ0221 CARBON RES. 1/4W J 220
Ω
R2009 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R2010 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R2011 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R2012 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R2013 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R2014 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
MISCELLANEOUS
B-24 1VM423185 21P PLATE EARTH
E7B20ED
JK2001 P000459840 JXGL210LY006 RGB CONNECTOR MRC-
021V-03 ABS(B11
JW2001 P000460080 WX1E7B20-002 FLAT CABLE 15P
AWG26#2651/P2.0/70
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
To Next Page
