Toshiba RD-XV47KB User Manual

20070312 1-20-1 E3B90CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
Comparison Chart of Models and Marks
Model Mark
RD-XV47-K-TE A
RD-XV47-K-TB B
RD-XV47-K-TF C
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
A-1X A,B P000483650 1VM222858 PANEL FRONT E3B90ED
A-1X C P000484080 1VM222861 PANEL FRONT E3B92FD
A-2 1VM120193K MAIN CHASSIS E4340UD
A-3 P000483660 1VM323660 COVER TOP(T-BLACK)
E3B90ED
A-5 1VM425152 FAN HOLDER ASSEMBLY
E43A0JD
A-7A 0VM416122 FOOT E6500UD
A-7B 0VM416122 FOOT E6500UD
A-11 1VM422956 CENTER CUSHION
E4350JD
A-16 1VM322233 POWER HOLDER
E434AED
1B1 P000472770 N25E1FL DECK ASSEMBLY
CZD014/VM25E0
1B3 P000475990 UHDD160VE002 ST3160212ACE
ST3160212ACE
B-1 1VM222703E HDD BRACKET E3A50JD
B-2 1VM422056 MODE LENS HOLDER
E4340UD
B-4 1VM422058 TAPE HIMELON(HDD)
E4340UD
B-7 0VM414677A PLATE EARTH E4321JD
DV-HD300
B-8 1VM120055G DECK PEDESTAL
E9600UD
B-11 0VM204534C FRONT BRACKET
E9400UD
B-12 0VM416269A FRONT BRACKET R
E9400UD
B-13 1VM424826 BRACKET R(T3) E3A50JD
B-14 0VM413956 TAPE HIMELON H9206JD
B-15 1VM422515 RUBBER
CUSHION(COVER TOP)
E4340UD
B-18 1VM422518 FRONT SUPPORT
E4340UD
B-19 1VM422517 SIDE CUSHION(COVER
TOP) E4340UD
B-20 1VM422534B RUBBER CUSHION
(MAIN CHASSIS)
E4340UD
B-21 1VM424843 HDD SUPPORT E3A50JD
B-22A 1VM422863 HDD RUBBER E4350JD
B-22B 1VM422863 HDD RUBBER E4350JD
B-22C 1VM422863 HDD RUBBER E4350JD
B-22D 1VM422863 HDD RUBBER E4350JD
B-25 0VM416664C CUSHION RUBBER
E9400UD
B-27 1VM121092 COVER DUST(T3)
E3B90ED
B-32 1VM425218 INSULATION SHEET
E3B90ED
FM1001 P000483830 MMEZR12XNR02 BRUSH LESS COOLING
FAN 2D65BK100090
L-1A GBHC3050 SCREW TAP TIGHT M3X5
BIND HEAD+BLK NI
L-1B GBHC3050 SCREW TAP TIGHT M3X5
BIND HEAD+BLK NI
L-1C GBHC3050 SCREW TAP TIGHT M3X5
BIND HEAD+BLK NI
L-1D GBHC3050 SCREW TAP TIGHT M3X5
BIND HEAD+BLK NI
L-1E GBHC3050 SCREW TAP TIGHT M3X5
BIND HEAD+BLK NI
L-1F GBHC3050 SCREW TAP TIGHT M3X5
BIND HEAD+BLK NI
L-1G GBHC3050 SCREW TAP TIGHT M3X5
BIND HEAD+BLK NI
L-3A GBHB3080 SCREW B-TIGHT M3X8
BIND HEAD+
L-3B GBHB3080 SCREW B-TIGHT M3X8
BIND HEAD+
L-3C GBHB3080 SCREW B-TIGHT M3X8
BIND HEAD+
L-4A GBHS3050 SCREW S-TIGHT M3*5
BIND+ 3*5 BIND+
L-4B GBHS3050 SCREW S-TIGHT M3*5
BIND+ 3*5 BIND+
L-5A GBJP3060 SCREW P-TIGHT M3X6
BIND HEAD+
L-5B GBJP3060 SCREW P-TIGHT M3X6
BIND HEAD+
L-6A GBJP3080 SCREW P-TIGHT M3X8
BIND HEAD+
L-6B GBJP3080 SCREW P-TIGHT M3X8
BIND HEAD+
L-6C GBJP3080 SCREW P-TIGHT M3X8
BIND HEAD+
L-6D GBJP3080 SCREW P-TIGHT M3X8
BIND HEAD+
L-6E GBJP3080 SCREW P-TIGHT M3X8
BIND HEAD+
L-6F GBJP3080 SCREW P-TIGHT M3X8
BIND HEAD+
L-6G GBJP3080 SCREW P-TIGHT M3X8
BIND HEAD+
L-7A GBJP3140 SCREW P-TIGHT 3X14
BIND HEAD +
L-7B GBJP3140 SCREW P-TIGHT 3X14
BIND HEAD +
L-8A 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-8B 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-8C 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9A 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9B 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9C 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9D 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9E 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9F 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9G 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9H 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9I 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9J 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9K 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9L 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9M 0VM412937A SCREW C-TIGHT M3X6
E5610UD
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
