SPECIFICATIONS
Note
• The specifications and design of this unit are subject to change without notice.
General
System HDD, DVD-Video, DVD-RW / R, DVD+RW / R, VCD, CD-DA,
CD-RW / R, Video Cassette Tape
VCR video heads Four heads
HDD Internal 3.5 inch HDD 160 GB
Power requirements 220–240 V ± 10%, 50 Hz ± 0.5%
Power consumption 60 W (standby: 8.0 W)
Weight 5.
5.9 kg (RD-XV47KB)
8 kg (RD-XV47KE/RD-XV47KF)
Dimensions (width x height x depth) 435 x 99.5 x 380 mm
Operating temperature 5°C to 40°C
Operating humidity Less than 80% (no condensation)
TV format P
PAL-I (RD-XV47KB)
SECAM LL, PAL B / G (RD-XV47KF)
AL / SECAM - BG / DK (RD-XV47KE)
Recording
Recording format Video Recording format (DVD-RW only),
Video format (DVD-RW, DVD-R)
+VR format (DVD+RW, DVD+R)
Recordable discs DVD-ReWritable, DVD-Recordable, DVD+ReWritable,
DVD+Recordable
Video recording format
Sampling frequency
Compression format
13.5 MHz
MPEG2
Audio recording format
Sampling frequency
Compression format
48 kHz
Dolby Digital
Tuner
Receivable channels E2-
IRA-E69 (RD-XV47KB)
"L (SECAM L)": F1 - E69 (RD-XV47KF)
"BG (PAL B / G)": E2 - E69 (RD-XV47KF)
E69 (RD-XV47KE)
Input/Output
Front Panel : (AV3)
Video input
Input level
One RCA connector
1 Vp-p (75 Ω)
S-Video input
Input level
One Mini DIN 4-pin jack
Y (Iuminance) 1 Vp-p (75 Ω)
C (colour) 300 mVp-p (75 Ω)
Audio input
Input level
Two RCA connectors
2 Vrms (input impedance: more than 10 kΩ)
Rear Panel
VHF/UHF antenna input/output terminal VHF/UHF set 75 Ω
Audio input /output Two 21-pin scart sockets (AV1, AV2)
Video input /output
Input /output level
Two 21-pin scart sockets (AV1, AV2)
1Vp-p (75 Ω) each
S-Video output
Output level
One Mini DIN 4-pin jacks
Y (Iuminance) 1 Vp-p (75 Ω)
C (colour) 300 mVp-p (75 Ω)
Component video out
Output level
Three RCA connectors
Y: 1.0 Vp-p (75 Ω)
P
B /C B , P R /C R : 0.7 Vp-p (75 Ω) each
Analogue audio output
Output level
Two RCA connectors
2 Vrms (output impedance: 680Ω)
Digital audio out
Output level
One Coaxial pin jack
500 mVp-p (75 Ω)

Toshiba RD-XV47KB Specifications

General

Brand	Toshiba
Model	RD-XV47KB
Category	DVD Recorder
Language	English
