20070312 1-21-1 E3B90EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
DVD MECHANISM & DVD/HDD MAIN
BOARD ASSEMBLY
POWER ASSEMBLY
BOARD POWER
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
RD-XV47-K-TE A
RD-XV47-K-TB B
RD-XV47-K-TF C
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
! P2 A P000483840 N78EJCEN DVD MECHANISM & DVD/
HDD MAIN BOARD
ASSEMBLY
! P2 B P000484060 N78EKCBN DVD MECHANISM & DVD/
HDD MAIN BOARD
ASSEMBLY
! P2 C P000484140 N78ELCFN DVD MECHANISM & DVD/
HDD MAIN BOARD
ASSEMBLY
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
! P1 A P000483770 1VSA15687 POWER ASSEMBLY
! P1 B P000484010 1VSA15558 POWER ASSEMBLY
! P1 C P000484130 1VSA15689 POWER ASSEMBLY
Consists of the following:
---------- ---------- BOARD POWER (BOARD
POWER A)
---------- ---------- BOARD POWER SWITCH
(BOARD POWER B)
P4 P000472720 1VSA13519 BOARD SENSOR
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
---------- BOARD POWER (BOARD
POWER A)
Consists of the following:
CAPACITORS
C251 CE1CMAVSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C252 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C253 CHD1JK30B102 CHIP CERAMIC
CAP.(1608) B K 1000pF/
50V
C254 CE1JMAVSL1R0 ELECTROLYTIC CAP. 1μF/
50V M H7
C301 CHD1JK30B223 CHIP CERAMIC
CAP.(1608) B K 0.022μF/
50V
C302 CE1JMAVSL1R0 ELECTROLYTIC CAP. 1μF/
50V M H7
C303 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C305 CE1JMAVSL1R0 ELECTROLYTIC CAP. 1μF/
50V M H7
C306 CHD1JK30B473 CHIP CERAMIC
CAP.(1608) B K 0.047μF/
50V
C307 CHD1JK30B223 CHIP CERAMIC
CAP.(1608) B K 0.022μF/
50V
C308 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C311 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C312 CE1CMAVSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C313 CE1JMAVSL1R0 ELECTROLYTIC CAP. 1μF/
50V M H7
C314 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C315 CHD1JK30B473 CHIP CERAMIC
CAP.(1608) B K 0.047μF/
50V
C316 CE1JMAVSL1R0 ELECTROLYTIC CAP. 1μF/
50V M H7
C317 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C318 A CHD1JK30B223 CHIP CERAMIC
CAP.(1608) B K 0.022μF/
50V
C324 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C325 CHD1JK30B822 CHIP CERAMIC CAP. B K
8200pF/50V
C326 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C328 CE0KMAVSL470 ELECTROLYTIC CAP.
47μF/6.3V M H7
C329 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C331 CE0KMAVSL221 ELECTROLYTIC CAP.
220μF/6.3V M H7
C332 CE1CMAVSL101 ELECTROLYTIC CAP.
100μF/16V M H7
C333 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C334 CE1JMAVSL1R0 ELECTROLYTIC CAP. 1μF/
50V M H7
C335 CE0KMAVSL101 ELECTROLYTIC CAP.
100μF/6.3V H7
C336 CHD1JJ3CH221 CHIP CERAMIC CAP. CH J
220pF/50V
C337 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C339 CHD1JJ3CH121 CHIP CERAMIC CAP. CH J
120pF/50V
C340 CE1JMAVSL1R0 ELECTROLYTIC CAP. 1μF/
50V M H7
C341 CHD1JD3CH100 CHIP CERAMIC
CAP.(1608) CH D 10pF/
50V
C342 CHD1JJ3CH102 CHIP CERAMIC
CAP.(1608) CH J 1000pF/
50V
C343 CE1CMAVSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C344 CP1EMAVSB4R7 ELECTROLYTIC CAP.
4.7μF/25V M NP H7
C345 CE1JMAVSLR47 ELECTROLYTIC CAP.
0.47μF/50V M H7
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
