Toshiba RD-XV47KB User Manual

20070312 1-21-2 E3B90EL
C346 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C347 CHD1EK30B104 CHIP CERAMIC
CAP.(1608) B K 0.1μF/25V
C349 CE1JMAVSLR47 ELECTROLYTIC CAP.
0.47μF/50V M H7
C350 CCA1JZTFZ104 CERAMIC CAP.(AX) F Z
0.1μF/50V
C370 C CCA1CMT0Y103 CERAMIC CAP.(AX) Y M
0.01μF/16V
C371 C CHD1JK30B223 CHIP CERAMIC
CAP.(1608) B K 0.022μF/
50V
C372 C CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C373 C CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C374 C CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C375 C CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C376 C CHD1JK30B223 CHIP CERAMIC
CAP.(1608) B K 0.022μF/
50V
C377 C CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C378 C CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C379 C CE1JMAVSLR47 ELECTROLYTIC CAP.
0.47μF/50V M H7
C381 C CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C382 C CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C383 C CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C384 C CE1JMAVSL2R2 ELECTROLYTIC CAP.
2.2μF/50V M H7
C402 CMA1JJP00183 FILM CAP.(P) 0.018μF/50V
J
C403 CCD2AKS0B471 CERAMIC CAP. B K
470pF/100V
C404 CE0KMAVSL221 ELECTROLYTIC CAP.
220μF/6.3V M H7
C405 CE0KMAVSL470 ELECTROLYTIC CAP.
47μF/6.3V M H7
C407 CHD1JK30B102 CHIP CERAMIC
CAP.(1608) B K 1000pF/
50V
C408 CHD1JK30B182 CHIP CERAMIC CAP. B K
1800pF/50V
C409 CHD1JJ3CH330 CHIP CERAMIC
CAP.(1608) CH J 33pF/50V
C410 CE1CMAVSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C411 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C412 CE0KMAVSL330 ELECTROLYTIC CAP.
33μF/6.3V M H7
C413 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C414 CHD1JK30B223 CHIP CERAMIC
CAP.(1608) B K 0.022μF/
50V
C415 CE1EMAVSL4R7 ELECTROLYTIC CAP.
4.7μF/25V M H7
C416 CHD1JK30B472 CHIP CERAMIC
CAP.(1608) B K 4700pF/
50V
C417 CE0KMAVSL220 ELECTROLYTIC CAP.
22μF/6.3V M H7
C418 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C419 CHD1JJ3CH221 CHIP CERAMIC CAP. CH J
220pF/50V
C421 CE0KMAVSL470 ELECTROLYTIC CAP.
47μF/6.3V M H7
C452 CE1CMAVSL100 ELECTROLYTIC CAP.
10μF/16V M H7
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
C453 CE1AMAVSL220 ELECTROLYTIC CAP.
22μF/10V M H7
C454 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C455 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C456 CE1CMAVSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C457 CE1EMAVSL4R7 ELECTROLYTIC CAP.
4.7μF/25V M H7
C458 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C461 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C462 CHD1JK30B472 CHIP CERAMIC
CAP.(1608) B K 4700pF/
50V
C463 CE1AMAVSL220 ELECTROLYTIC CAP.
22μF/10V M H7
C464 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C465 CE1CMAVSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C466 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C468 CE0KMAVSL221 ELECTROLYTIC CAP.
220μF/6.3V M H7
C469 CE1AMAVSL220 ELECTROLYTIC CAP.
22μF/10V M H7
C470 CHD1JK30B472 CHIP CERAMIC
CAP.(1608) B K 4700pF/
50V
C471 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C472 CE1EMAVSL4R7 ELECTROLYTIC CAP.
4.7μF/25V M H7
C473 CE1CMAVSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C474 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C475 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C476 CE0KMAVSL220 ELECTROLYTIC CAP.
22μF/6.3V M H7
C478 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C479 CE1CMAVSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C480 CE1CMASDL100 ELECTROLYTIC CAP.
10μF/16V M
C481 CE1CMAVSL100 ELECTROLYTIC CAP.
10μ
F/16V M H7
C482 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C483 CE1EMAVSL4R7 ELECTROLYTIC CAP.
4.7μF/25V M H7
C484 CE1EMAVSL4R7 ELECTROLYTIC CAP.
4.7μF/25V M H7
C485 CE1CMAVSL100 ELECTROLYTIC CAP.
10μF/16V M H7
C486 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C487 CE1CMAVSL470 ELECTROLYTIC CAP.
47μF/16V M H7
C488 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C502 CHD1JK30B223 CHIP CERAMIC
CAP.(1608) B K 0.022μF/
50V
C505 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C506 CE1JMASDL1R0 ELECTROLYTIC CAP. 1μF/
50V M
C507 CHD1JK30B102 CHIP CERAMIC
CAP.(1608) B K 1000pF/
50V
C508 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
