Toshiba RD-XV47KB User Manual

20070312 1-21-11 E3B90EL
BOARD POWER SWITCH
BOARD SENSOR
BOARD PW/SW
BOARD POWER SUPPLY
VR501 VRCB104HH014 CARBON P.O.T. VZ067TL1
B104 PB(F)
X301 P000468200 FXC445LLN004 XTAL 4.433619MHz
X501 P000468220 FXD126LCHE01 QUARTS CRYSTAL
12.000000MHz
X1501 P000483780 FXC323LQUA03 RESONATOR XTAL
32.768kHz QTF38-
32.768K125P15L
X1502 P000483790 FXD106LLN002 QUARTZ CRYSTAL
C49SJJ11640-10.000M
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
---------- BOARD POWER SWITCH
(BOARD POWER B)
Consists of the following:
DIODE
D1605 NPQZ1CHJGTN
N
LED(GREEN)
LTL1CHJGTNN
SWITCH
SW1601 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
MISCELLANEOUS
W6 P000472880 WX1E4340-006 PARALLEL WIRE 4P
AWG26#2651/ 126MM
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
P4 P000472720 1VSA13519 BOARD SENSOR
Consists of the following:
TRANSISTORS
Q503 NPWZT2046B12 PHOTO TRANSISTOR
PT204-6B-12
Q504 NPWZT2046B12 PHOTO TRANSISTOR
PT204-6B-12
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
! P3 A,C ---------- 1VSA15686 BOARD PW/SW
! P3 B ---------- 1VSA15561 BOARD PW/SW
Consists of the following:
! P3-4 A,C P000483760 1VSA15686-4 BOARD POWER SUPPLY
(PW/SW-A)
! P3-4 B P000484050 1VSA15561-4 BOARD POWER SUPPLY
(PW/SW-A)
P3-2 A,C P000483740 1VSA15686-2 BOARD FRONT JACK
(PW/SW-B)
P3-2 B P000484030 1VSA15561-2 BOARD FRONT JACK
(PW/SW-B)
P3-1 A,C P000483730 1VSA15686-1 BOARD SWITCH (PW/
SW-C)
P3-1 B P000484020 1VSA15561-1 BOARD SWITCH (PW/
SW-C)
P3-3 A,C P000483750 1VSA15686-3 BOARD REAR JACK (PW/
SW-D)
P3-3 B P000484040 1VSA15561-3 BOARD REAR JACK (PW/
SW-D)
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
! P3-4 A,C P000483760 1VSA15686-4 BOARD POWER SUPPLY
(PW/SW-A)
! P3-4 B P000484050 1VSA15561-4 BOARD POWER SUPPLY
(PW/SW-A)
Consists of the following:
CAPACITORS
C013 CE1JMZADL471 ELECTROLYTIC CAP
470μF/50V M
C014 CE1EMASDL471 ELECTROLYTIC CAP.
470μF/25V M
C020 CE1JMASDL220 ELECTROLYTIC CAP.
22μF/50V M
C022 CE1GMASDL471 ELECTROLYTIC CAP.
470μF/35V M
! C1001 CT2E683DC016 ACROSS THE LINE CAP.
0.068μF/250V
C1004 CA2H221S6029 ELECTROLYTIC CAP.
220μF/400V M
! C1006 CCN2EMA0E222 SAFTY CAP. 2200pF/250V
C1029 CCD3DKP0B151 CERAMIC CAP. B K
150pF/2KV
C1030 CA2A683DT018 POLYESTER FILM CAP.
(PB FREE) 0.068μF/100V J
C1034 CA1J393MS029 FILM CAP.(P) 0.039μF/50V
J
C1035 CE0KMZADL332 ELECTROLYTIC CAP.
3300μF/6.3V SL
C1036 CCD2JKP0B471 CERAMIC CAP. B K
470pF/500V
C1037 CE1EMZADL222 ELECTROLYTIC CAP.
2200μF/25V SL
C1039 CE1CMASDL471 ELECTROLYTIC CAP.
470μF/16V M
C1100 CA2A682DT018 POLYESTER FILM CAP.
(PB FREE) 0.0068μF/100V
J
C1102 CCD2JKP0B471 CERAMIC CAP. B K
470pF/500V
C1104 CE1AMZADL472 ELECTRIC CAP. 4700μF/
10V
C1105 CE1AMZADL472 ELECTRIC CAP. 4700μF/
10V
C1107 CE1AMZADL222 ELECTROLYTIC CAP.
2200μF/10V SL
C1110 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
C1112 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C1113 CHD1JK30B104 CHIP CERAMIC
CAP.(1608) B K 0.1μF/50V
C1114 CE0KMASDL102 ELECTROLYTIC CAP.
1000μF/6.3V M
C1115 CE0KMASDL102 ELECTROLYTIC CAP.
1000μF/6.3V M
C1116 CE0KMASDL101 ELECTROLYTIC CAP.
100μF/6.3V M
C1117 CE1CMASDL470 ELECTROLYTIC CAP.
47μF/16V M
C1118 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01
μF/
50V
C1119 CE1CMASDL471 ELECTROLYTIC CAP.
470μF/16V M
C1121 CE1CMASDL470 ELECTROLYTIC CAP.
47μF/16V M
C1126 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C1127 CE0KMASDL101 ELECTROLYTIC CAP.
100μF/6.3V M
C1128 CE0KMASDL101 ELECTROLYTIC CAP.
100μF/6.3V M
C1129 CE0KMASDL101 ELECTROLYTIC CAP.
100μF/6.3V M
C1130 CHD1JK30B104 CHIP CERAMIC
CAP.(1608) B K 0.1μF/50V
C1131 CHD1JK30B104 CHIP CERAMIC
CAP.(1608) B K 0.1μF/50V
