20070312 1-21-10 E3B90EL
R1711 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1712 RRXAJR5Z0182 CHIP RES. 1/10W J 1.8k Ω
R1713 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R1714 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R1715 RRXAJR5Z0223 CHIP RES. 1/10W J 22k Ω
R1717 RCX4JATZ0221 CARBON RES. 1/4W J 220
Ω
R1718 RCX4JATZ0750 CARBON RES. 1/4W J 75
Ω
R1719 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R1720 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1721 RRXAJR5Z0153 CHIP RES. 1/10W J 15k Ω
R1722 RCX4JATZ0182 CARBON RES. 1/4W J
1.8k Ω
R1723 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1724 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1725 RRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R1726 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R1728 RRXAJR5Z0104 CHIP RES. 1/10W J 100k
Ω
R1729 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1730 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1731 RCX4JATZ0471 CARBON RES. 1/4W J 470
Ω
R1732 RCX4JATZ0471 CARBON RES. 1/4W J 470
Ω
R1733 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1734 RCX4JATZ0750 CARBON RES. 1/4W J 75
Ω
R1735 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1736 RCX4JATZ0271 CARBON RES. 1/4W J 270
Ω
R1737 RCX4JATZ0750 CARBON RES. 1/4W J 75
Ω
R1738 RCX4JATZ0750 CARBON RES. 1/4W J 75
Ω
R1739 RCX6JATZ0101 CARBON RES. 1/6W J 100
Ω
R1740 RCX4JATZ0750 CARBON RES. 1/4W J 75
Ω
R1741 RCX4JATZ0750 CARBON RES. 1/4W J 75
Ω
R1742 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R1743 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R1744 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R1745 RRXAJR5Z0331 CHIP RES. 1/10W J 330 Ω
R1746 RRXAJR5Z0331 CHIP RES. 1/10W J 330 Ω
R1748 RRXAJR5Z0331 CHIP RES. 1/10W J 330 Ω
R1749 RRXAJR5Z0331 CHIP RES. 1/10W J 330 Ω
R1750 RRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R1751 RRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R1753 JW5.0T BOARD JUMPER D0.6-
P5.0
R1754 JW5.0T BOARD JUMPER D0.6-
P5.0
R1755 RRXAJR5Z0105 CHIP RES. 1/10W J 1M Ω
R1756 RRXAJR5Z0105 CHIP RES. 1/10W J 1M Ω
R1757 RRXAJR5Z0105 CHIP RES. 1/10W J 1M Ω
R1758 RRXAJR5Z0105 CHIP RES. 1/10W J 1M Ω
R1759 RCX6JATZ0331 CARBON RES. 1/6W J 330
Ω
R1760 RRXAJR5Z0100 CHIP RES. 1/10W J 10 Ω
R1761 RRXAJR5Z0100 CHIP RES. 1/10W J 10 Ω
R1762 RRXAJR5Z0330 CHIP RES. 1/10W J 33 Ω
R1763 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1764 JW5.0T BOARD JUMPER D0.6-
P5.0
R1767 RRXAJR5Z0474 CHIP RES. 1/10W J 470k
Ω
R1769 RRXAJR5Z0183 CHIP RES. 1/10W J 18k Ω
R1770 RRXAJR5Z0183 CHIP RES. 1/10W J 18k Ω
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
R1771 RCX6JATZ0123 CARBON RES. 1/6W J 12k
Ω
R1772 RRXAJR5Z0123 CHIP RES. 1/10W J 12k Ω
R1773 RRXAJR5Z0151 CHIP RES. 1/10W J 150 Ω
R1775 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1776 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1777 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1778 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1779 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1780 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω
R1781 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1782 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R1783 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R1784 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1785 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
SWITCHES
SW506 P000465640 SSC0101MCE03 LEAF SWITCH
MXS01830MVP0
SW507 P000480780 SSR0106KB004 SWITCH ROTARY SSS-
53MD-1
SW521 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW522 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW523 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW524 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW525 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW1501 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW1502 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
MISCELLANEOUS
B-9H 0VM409508 BUSH LED(F) H3700UD
B-9I 0VM409508 BUSH LED(F) H3700UD
B-10 1VM425280 SHIELD ASSEMBLY(T3
PAL) E3B90ED
B-16 0VM412870 DOUBLE SIDE TAPE
HB200UD
B-31 0VM304573 ROHM HOLDER H7770JD
FL601 P000472820 TVFD1C0FT050 VFD 7-BT-306NS
JK1502 P000465520 JXRL010LY140 JACK RCA MSP-281V41-
B(B110)
JK1503 P000465530 JXRL020LY120 JACK RCA MSP-382V-12
NILF
JK1504 P000459850 JXGL210LY008 RGB CONNECTOR MRC-
021V-05 ABS(B110
JK1505 P000465540 JXRL030LY116 JACK RCA MSP-213V1-
652-B NI L
JK1510 P000457070 JXEL040LY003 JACK S TYPE MDC-050V-
2.4 LF(B110
L-2 GBCP3080 SCREW P-TIGHT M3X8
BIND HEAD+
L-9P 0VM412937A SCREW C-TIGHT M3X6
E5610UD
PS502 QPWZP1302C70 PHOTO INTERRUPTER
RPI-302C70
RS1501 P000457340 USESJRSKK039 REMOTE RECEIVER PIC-
37043LU
TP301 JW7.0T BOARD JUMPER D0.6-
P7.0
TP502 JW9.0T BOARD JUMPER D0.6-
P9.0
TP503 JW7.0T BOARD JUMPER D0.6-
P7.0
TP504 JW15.0T BOARD JUMPER D0.6-
P15.0
! TU1501 A,B P000483920 UTUNPLGAL020 TUNER UNIT TMFE2-
303A
! TU1501 C P000484150 UTUNPSLAL007 TUNER UNIT TMFE2-
405A
W1 P000483930 WX1E3B00-001 FFC AV-MAIN 30P 30PIN/
TL335MM
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
