1-17-1 E3B90PIN
IC PIN FUNCTION DESCRIPTIONS
< VCR Section >
Comparison Chart of Models and Marks
IC501 ( SERVO / SYSTEM CONTROL )
Model Mark
RD-XV47KE A
RD-XV47KB B
RD-XV47KF C
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
1-
NU Not Used
2IN
PG-DELAY
Video Head Switching
Pulse Signal Adjusted
Voltage
3 IN POW-SAF
P-ON Power Detection
Input Signal
4IN
END-S
Tape End Position
Detect Signal
5-
NU Not Used
6IN
V-ENV
Video Envelope
Comparator Signal
7IN
KEY-1 Key Data Input 1
8-
NU Not Used
9IN
LD-SW
Deck Mode Position
Detector Signal
10 IN
ST-S
Tape Start Position
Detector Signal
11 -
NU Not Used
12 -
NU Not Used
13 OUT
D-V- SYNC Dummy V-sync Output
14 IN
REMOTE Remote Signal Input
15 OUT
C-ROTA
Color Phase Rotary
Changeover Signal
16 OUT
H-A-SW
Video Head Amp
Switching Pulse
17 IN
H-A-COMP
Head Amp Comparator
Signal
18 OUT
RF-SW
Video Head Switching
Pulse
19 OUT
Hi-Fi-H-SW
HiFi Audio Head
Switching Pulse
20 -
NU Not Used
21 -
NU Not Used
22 -
NU Not Used
23 -
NU Not Used
24 -
NU Not Used
25 -
NU Not Used
26 OUT REC-LED
Rec LED Control Signal
27 -
NU Not Used
28 -
NU Not Used
29 -
NU Not Used
30 -
NU Not Used
31 IN
REC-SAF-
SW
Recording Safety SW
Detect (With Record
tab=”L”/ With out Record
tab=”H”)
32 IN
A-MODE
Hi-Fi Tape Detection
Signal
33 OUT
D-REC-H Delayed Record Signal
34 IN
RESET
Micro Controller Reset
Signal
35 IN
NU Ground
36 OUT
NU Not Used
37 -
Vcc
Always +5V with AC
Plug Connected
38 IN
Xin Main Clock Input
39 OUT
Xout Main Clock Output
40 -
Vss Ground
41 -
NU Not Used
42 -
NU Not Used
43 IN
CLKSEL Clock Select
44 IN
OSCin
Clock Input for letter
size
45 OUT
OSCout
Clock Output for letter
size
46 -
NU Ground
47 IN
LP LP
48 IN
FSC-IN
[4.43MHz]
4.43MHz Clock Input
49 -
OSDVss Ground
50 IN
OSD-V-IN OSD Video Signal Input
51 -
NU Not Used
52 OUT
OSD-V-
OUT
OSD Video Signal
Output
53 -
OSDVcc
+5V Power Supply
(OSD)
54 -
HLF
LPF Connected
Terminal (Slicer)
55
A,C IN
COLOR-IN
SECAM or MESECAM
Chroma Video Input
Signal at Super Impose
B-
NU Not Used
56 -
NU Not Used
57 -
NU Ground
58 IN
C-SYNC
Composite
Synchronized Pulse
59 -
NU Not Used
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
