Toshiba RD-XV47KB User Manual

20070312 1-21-14 E3B90EL
BOARD FRONT JACK
R1149 RCX4JATZ0682 CARBON RES. 1/4W J
6.8k Ω
R1150 RCX4JATZ0682 CARBON RES. 1/4W J
6.8k Ω
R1151 RRXAFR5H1000 CHIP RES. 1/10W F 100 Ω
R1152 RRXAFR5H2200 CHIP RES. 1/10W F 220 Ω
R1153 RRXAFR5H1501 CHIP RES. 1/10W F 1.5k Ω
R1154 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1155 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1157 RCX4JATZ0222 CARBON RES. 1/4W J
2.2k Ω
R1158 RRXAFR5H0100 CHIP RES.(1608) 1/10W F
10 Ω
R1159 RRXAJR5Z0330 CHIP RES. 1/10W J 33 Ω
R1160 RCX6JATZ0224 CARBON RES. 1/6W J
220k Ω
R1161 RCX4JATZ0824 CARBON RES. 1/4W J
820k Ω
R1162 RCX4JATZ0180 CARBON RES. 1/4W J 18
Ω
R1163 RCX4JATZ0221 CARBON RES. 1/4W J 220
Ω
R1164 RCX4JATZ0221 CARBON RES. 1/4W J 220
Ω
R1165 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω
R1166 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω
R1167 RRXAJR5Z0562 CHIP RES. 1/10W J 5.6k Ω
R1170 RCX4JATZ0121 CARBON RES. 1/4W J 120
Ω
R1171 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1172 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1174 RRXAFR5H3300 CHIP RES. 1/10W F 330 Ω
R1177 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
MISCELLANEOUS
! AC1001 A,C WAE0172LW011 POWER CORD
PE8G2CG9G0AB05
! AC1001 B WAB0182LW016 POWER CORD
PE8G2X91H0AA061
B-5A 1VM424636 HEAT SINK E2A00JD
B-5B 1VM425352 POWER HEATSINK
E3B90ED
CL1001 JC96J30ER007 FFC CONNECTOR 30PIN
IMSA-9615S-30A-PP-A
! F1001 P000483870 PEG20B0W3002 FUSE TIME RAG
TSD2A250VSVDEUC3CP
SE
FH1001 XH01Z00LY002 FUSE HOLDER MSF-015
LF (B110)
FH1002 XH01Z00LY002 FUSE HOLDER MSF-015
LF (B110)
L-9N 0VM412937A SCREW C-TIGHT M3X6
E5610UD
L-9O 0VM412937A SCREW C-TIGHT M3X6
E5610UD
! SA1001 P000457210 NVQZ10D471KB SURGE ABSORBER
470V+-10PER
! T1001 P000483810 LTT3PE0XB006 TRANS POWER BCK-35-
0341
W2 P000483940 WX1E3B00-002 FFC PW-MAIN 30P 30PIN/
TL313MM
W3 P000483950 WX1E3B00-003 FFC AV-PW 30P 30PIN/
TL90MM
W4 P000483960 WX1E3B00-004 FFC AV-SW 20P 20PIN/
TL136MM
W8 P000472900 WX1E4340-008 WIRE ASSEMBLY 4P
AWG22/ 105MM
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
P3-2 A,C P000483740 1VSA15686-2 BOARD FRONT JACK
(PW/SW-B)
P3-2 B P000484030 1VSA15561-2 BOARD FRONT JACK
(PW/SW-B)
Consists of the following:
CAPACITORS
C3006 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C3007 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
CONNECTOR
CN3001 JCFNG20JG022 FMN CONNECTOR SIDE
20P 20FMN-STRK-
A(LF)(SN)
DIODES
D3001 NPQZ0012541T LED(RED) 1254IT
D3002 NPQZ0012541T LED(RED) 1254IT
D3003 NPQZ1CHJGTN
N
LED(GREEN)
LTL1CHJGTNN
D3004 NPQ3L1CHCBK2 LED(BLUE) LTL1CHCBK2-
F
D3005 NPQZ1CHKYKN
N
LED(AMBER YELLOW)
LTL1CHKYKNN
D3008 QDTB0MTZJ6R2 ZENER DIODE MTZJT-
776.2B
D3009 QDTB0MTZJ6R2 ZENER DIODE MTZJT-
776.2B
D3010 QDTB0MTZJ6R2 ZENER DIODE MTZJT-
776.2B
D3011 QDTB0MTZJ6R2 ZENER DIODE MTZJT-
776.2B
RESISTORS
R3001 RCX4JATZ0331 CARBON RES. 1/4W J 330
Ω
R3002 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R3003 RCX4JATZ0331 CARBON RES. 1/4W J 330
Ω
R3004 RCX4JATZ0271 CARBON RES. 1/4W J 270
Ω
R3005 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R3006 RRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R3007 RRXAJR5Z0750 CHIP RES. 1/10W J 75 Ω
R3008 RRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R3010 RCX4JATZ0821 CARBON RES. 1/4W J 820
Ω
R3011 RCX4JATZ0681 CARBON RES. 1/4W J 680
Ω
R3013 RRXAJR5Z0301 CHIP RES. 1/10W J 300 Ω
R3014 RRXAJR5Z0361 CHIP RES. 1/10W J 360 Ω
R3015 RRXAJR5Z0621 CHIP RES. 1/10W J 620 Ω
R3016 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R3017 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R3018 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R3022 RCX4JATZ0331 CARBON RES. 1/4W J 330
Ω
R3023 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R3026 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R3029 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R3032 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R3035 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R3038 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
SWTICHES
SW3001 P000472810 SST0101HH036 SWITCH TACT KSM0634B
PB(F)
SW3002 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
SW3003 P000483300 SST0101AL041 TACT SWITCH
SKQSAF001A
