20070312 1-21-13 E3B90EL
L1001-2 XL03010XM001 BEAD CORE B16 RH
3.5X10X1.3
L1002 ---------- BEAD CORE
ASSEMBLYE3B91BD
L1002-1 JW20.0T BOARD JUMPER D0.6-
P20.0
L1002-2 XL03010XM001 BEAD CORE B16 RH
3.5X10X1.3
! L1003 P000483800 LLEG0Z0TU001 COIL LINE FILTER 56MH
TLF24HB5630R3
L1004 ---------- BEAD CORE
ASSEMBLYE3B91BD
L1004-1 JW20.0T BOARD JUMPER D0.6-
P20.0
L1004-2 XL03010XM001 BEAD CORE B16 RH
3.5X10X1.3
L1005 ---------- BEAD CORE
ASSEMBLYE3B91BD
L1005-1 JW20.0T BOARD JUMPER D0.6-
P20.0
L1005-2 XL03010XM001 BEAD CORE B16 RH
3.5X10X1.3
L1013 LLC220KKV007 POWER INDUCTORS
TWKBNP-220K
L1014 LLC100KTU026 RADIAL LEADED
INDUCTOR
LHL13NB100K
L1100 LLC180KKV007 POWER INDUCTORS
TWKBNP-180K
L1101 LLC180KKV007 POWER INDUCTORS
TWKBNP-180K
TRANSISTORS
! Q1001 QFWZ2SK3798Q MOS FET 2SK3798(Q)
Q1003 QQSY2SC2120F TRANSISTOR 2SC2120-
Y(TE2 F T)
Q1100 NQEYKTC2026P TRANSISTOR(PB FREE)
KTC2026-Y/P
Q1101 NQS4KTA1266P TRANSISTOR KTA-1266-
GR-AT/P
Q1102 NQEY0KTB1151 TRANSISTOR KTB1151-Y-
U/P
Q1103 NQSYKTC3199P TRANSISTOR KTC3199-Y-
AT / P
Q1104 NQSYKTC3203P TRANSISTOR KTC3203-Y-
AT / P
Q1105 NQSYKTC3199P TRANSISTOR KTC3199-Y-
AT / P
Q1106 NQS4KTC3266P TRANSISTOR KTC3266-
GR-AT/P
Q1107 NQSZKRC103MP NPN TRANSISTOR
KRC103M-AT/P
Q1108 NQEYKTC2026P TRANSISTOR(PB FREE)
KTC2026-Y/P
Q1114 NQSYKTA1267P TRANSISTOR KTA1267-Y-
AT / P
Q1115 NQSZKRC103MP NPN TRANSISTOR
KRC103M-AT/P
RESISTORS
R068 RRXAJR5Z0223 CHIP RES. 1/10W J 22k Ω
! R1001 RCX2565FS001 CARBON RES. 1/2W K
5.6M Ω
R1003 RW031R5PAK10 CEMENT RESISTOR 3W
K 1.5 Ω
R1004 RW051R0PAK10 CEMENT RESISTOR 5W
J 1.0 Ω H 10MM
R1005 RCX4JATZ0564 CARBON RES. 1/4W J
560k Ω
R1006 RCX4JATZ0684 CARBON RES. 1/4W J
680k Ω
R1007 RCX4JATZ0684 CARBON RES. 1/4W J
680k Ω
R1008 RCX4JATZ0824 CARBON RES. 1/4W J
820k Ω
R1009 RCX4JATZ0220 CARBON RES. 1/4W J 22
Ω
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
R1029 RCX4JATZ0184 CARBON RES. 1/4W J
180k Ω
R1033 RCX4JATZ0560 CARBON RES. 1/4W J 56
Ω
R1035 JW5.0T BOARD JUMPER D0.6-
P5.0
R1036 RCX4JATZ0221 CARBON RES. 1/4W J 220
Ω
R1037 RCX4JATZ0221 CARBON RES. 1/4W J 220
Ω
R1039 RCX4JATZ0122 CARBON RES. 1/4W J
1.2k Ω
R1043 RCX4JATZ0152 CARBON RES. 1/4W J
1.5k Ω
R1097 RRXAJR5Z0391 CHIP RES. 1/10W J 390 Ω
R1101 RRXAJR5Z0681 CHIP RES. 1/10W J 680 Ω
R1102 RRXAFR5H2001 CHIP RES. 1/10W F 2k Ω
R1104 RCX4JATZ0182 CARBON RES. 1/4W J
1.8k Ω
R1106 RRXAR47HH007 CHIP RES.(1608) 1/10W J
0.47 Ω
R1107 RCX4JATZ0102 CARBON RES. 1/4W J 1k
Ω
R1108 RCX4JATZ0152 CARBON RES. 1/4W J
1.5k Ω
R1110 RCX4JATZ0102 CARBON RES. 1/4W J 1k
Ω
R1112 RRXAFR5H3000 CHIP RES. 1/10W F 300 Ω
R1113 RRXAFR5H1001 CHIP RES. 1/10W F 1.0k Ω
R1114 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1115 RRXAFR5H1001 CHIP RES. 1/10W F 1.0k Ω
R1117 RCX4JATZ0222 CARBON RES. 1/4W J
2.2k Ω
R1118 RN03751ZU001 METAL OXIDE FILM RES.
3W J 750 Ω
R1119 RRXAJR5Z0224 CHIP RES. 1/10W J 220k
Ω
R1120 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1123 RCX4JATZ0272 CARBON RES. 1/4W J
2.7k Ω
R1124 RCX4JATZ0112 CARBON RES. 1/4W J
1.1k Ω
R1125 RCX4JATZ0112 CARBON RES. 1/4W J
1.1k Ω
R1126 RCX4JATZ0682 CARBON RES. 1/4W J
6.8k Ω
R1127 RCX4JATZ0112 CARBON RES. 1/4W J
1.1k Ω
R1128 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1129 RCX6JATZ0104 CARBON RES. 1/6W J
100k Ω
R1130 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1131 RRXAFR5H1802 CHIP RES. 1/10W F 18k Ω
R1132 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1133 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω
R1134 RCX4JATZ0271 CARBON RES. 1/4W J 270
Ω
R1135 RRXAFR5H4701 CHIP RES. 1/10W F 4.7k Ω
R1136 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω
R1138 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R1139 RRXAJR5Z0682 CHIP RES. 1/10W J 6.8k Ω
R1140 RCX6JATZ0561 CARBON RES. 1/6W J 560
Ω
R1141 RCX4JATZ0272 CARBON RES. 1/4W J
2.7k Ω
R1142 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R1143 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R1144 RRXAFR5H1002 CHIP RES. 1/10W F 10k Ω
R1145 RRXAFR5H1002 CHIP RES. 1/10W F 10k Ω
R1146 RRXAFR5H1502 CHIP RES. 1/10W F 15k Ω
R1147 RRXAFR5H1002 CHIP RES. 1/10W F 10k Ω
R1148 RCX4JATZ0682 CARBON RES. 1/4W J
6.8k Ω
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
