20070312 1-21-12 E3B90EL
C1132 CE0KMASDL102 ELECTROLYTIC CAP.
1000μF/6.3V M
C1133 CA2A102DT018 POLYESTER FILM CAP.
(PB FREE) 0.001μF/100V J
C1138 CE1CMASDL101 ELECTROLYTIC CAP.
100μF/16V M
C1139 CHD1JK30B104 CHIP CERAMIC
CAP.(1608) B K 0.1μF/50V
C1140 CE1CMASDL101 ELECTROLYTIC CAP.
100μF/16V M
C1141 CHD1JK30B104 CHIP CERAMIC
CAP.(1608) B K 0.1μF/50V
C1142 CHD1JK30B104 CHIP CERAMIC
CAP.(1608) B K 0.1μF/50V
C1143 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
CONNECTORS
CN1001 JC96J30ER007 FFC CONNECTOR 30PIN
IMSA-9615S-30A-PP-A
CN1002 J3PHC02JG017 PH CONNECTOR
(WHITE) TOP 2P B2B-PH-
K-S(LF)
DIODES
D012 NDQZ000BA158 RECTIFIER DIODE BA158
D013 NDQZ000BA158 RECTIFIER DIODE BA158
D014 NDQZ000SB390 SCHOTTKY BARRIER
DIODE SB390
D015 NDLZ001N5397 DIODE 1N5397-B
D016 NDQZ000SB340 SCHOTTKY BARRIER
DIODE SB340
D017 QDTB00MTZJ16 ZENER DIODE MTZJT-
7716B
D018 NDQZ000BA158 RECTIFIER DIODE BA158
D019 NDQZ000FR203 RECTIFIER DIODE
FR203-B/P
D020 JW5.0T BOARD JUMPER D0.6-
P5.0
D1001 NDLZ001N5397 DIODE 1N5397-B
D1002 NDLZ001N5397 DIODE 1N5397-B
D1003 NDLZ001N5397 DIODE 1N5397-B
D1004 NDLZ001N5397 DIODE 1N5397-B
D1006 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1011 QDTB00MTZJ27 ZENER DIODE MTZJT-
7727B
D1022 QDTB0MTZJ5R6 ZENER DIODE MTZJT-
775.6B
D1023 QDTA00MTZJ36 ZENER DIODE MTZJT-
7736A
D1025 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1030 NDQZ000SB340 SCHOTTKY BARRIER
DIODE SB340
D1031 NDQZ000SB390 SCHOTTKY BARRIER
DIODE SB390
D1032 NDQZ000SB340 SCHOTTKY BARRIER
DIODE SB340
D1035 NDQZ000SB390 SCHOTTKY BARRIER
DIODE SB390
D1101 NDQZ000SB340 SCHOTTKY BARRIER
DIODE SB340
D1102 QDTB0MTZJ6R8 ZENER DIODE MTZJT-
776.8B
D1103 NDQZ000BA157 RECTIFIER DIODE BA157
D1107 JW5.0T BOARD JUMPER D0.6-
P5.0
D1108 QDTB00MTZJ18 ZENER DIODE MTZJT-
7718B
D1109 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1110 QDTB00MTZJ24 ZENER DIODE MTZJT-
7724B
D1112 JW5.0T BOARD JUMPER D0.6-
P5.0
D1113 JW5.0T BOARD JUMPER D0.6-
P5.0
D1114 JW5.0T BOARD JUMPER D0.6-
P5.0
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
D1115 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1116 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1117 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1118 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1119 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1120 QDTB00MTZJ10 ZENER DIODE MTZJT-
7710B
D1121 JW10.0T BOARD JUMPER D0.6-
P10.0
D1122 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1123 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1124 QDTB0MTZJ9R1 ZENER DIODE MTZJT-
779.1B
D1125 QDTB00MTZJ15 ZENER DIODE MTZJT-
7715B
D1126 NDQZ001N4005 RECTIFIER DIODE
1N4005
D1127 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1128 NDQZ000SB140 SCHOTTKY BARRIER
DIODE SB140
D1129 QDTB0MTZJ6R8 ZENER DIODE MTZJT-
776.8B
D1130 QD1Z001SS400 SWITCHING DIODE
1SS400 TE61
D1131 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1132 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1133 QD1Z001SS400 SWITCHING DIODE
1SS400 TE61
D1134 QD1Z001SS400 SWITCHING DIODE
1SS400 TE61
D1135 NDLZ001N5397 DIODE 1N5397-B
D1136 NDLZ001N5397 DIODE 1N5397-B
D1137 QD1Z001SS400 SWITCHING DIODE
1SS400 TE61
D1138 QD1Z001SS400 SWITCHING DIODE
1SS400 TE61
D1139 QD1Z001SS400 SWITCHING DIODE
1SS400 TE61
D1140 QDLZ001ZC43Q DIODE 1ZC43(Q)
D1142 QD1Z001SS400 SWITCHING DIODE
1SS400 TE61
D1144 QD1Z001SS400 SWITCHING DIODE
1SS400 TE61
D1145 QD1Z001SS400 SWITCHING DIODE
1SS400 TE61
D1146 NDQZ000SB340 SCHOTTKY BARRIER
DIODE SB340
D1147 NDQZ000SB140 SCHOTTKY BARRIER
DIODE SB140
D1148 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
ICS
! IC1001 P000459900 NPEA000EL817 PHOTOCOUPLER
EL817A
IC1101 P000459940 NSZBA0TJY036 IC SHUNT REGULATOR
KIA431-AT/P
IC1102 P000459940 NSZBA0TJY036 IC SHUNT REGULATOR
KIA431-AT/P
IC1103 P000457260 QSZBA0SSH054 VOLTAGE REGULATOR
PQ070XF01SZH
IC1104 P000457260 QSZBA0SSH054 VOLTAGE REGULATOR
PQ070XF01SZH
IC1105 P000483860 NSZBA0STY245 IC REGULATOR TLV1117I
TO-220
COILS
L1001 ---------- BEAD CORE
ASSEMBLYE3B91BD
L1001-1 JW20.0T BOARD JUMPER D0.6-
P20.0
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
To Next Page
