20070312 1-21-9 E3B90EL
R1585 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1586 RRXAJR5Z0202 CHIP RES. 1/10W J 2k Ω
R1587 RRXAJR5Z0202 CHIP RES. 1/10W J 2k Ω
R1588 RRXAJR5Z0332 CHIP RES. 1/10W J 3.3k Ω
R1590 RCX4JATZ0182 CARBON RES. 1/4W J
1.8k Ω
R1594 JW5.0T BOARD JUMPER D0.6-
P5.0
R1595 RCX4JATZ0391 CARBON RES. 1/4W J 390
Ω
R1599 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1600 JW5.0T BOARD JUMPER D0.6-
P5.0
R1601 JW5.0T BOARD JUMPER D0.6-
P5.0
R1602 JW5.0T BOARD JUMPER D0.6-
P5.0
R1603 JW5.0T BOARD JUMPER D0.6-
P5.0
R1604 RCX6JATZ0473 CARBON RES. 1/6W J 47k
Ω
R1605 RCX4JATZ0681 CARBON RES. 1/4W J 680
Ω
R1606 RCX4JATZ0681 CARBON RES. 1/4W J 680
Ω
R1608 RRXAFR5H2400 CHIP RES. 1/10W F 240 Ω
R1609 RRXAFR5H2200 CHIP RES. 1/10W F 220 Ω
R1610 RRXAFR5H2200 CHIP RES. 1/10W F 220 Ω
R1611 RRXAFR5H2200 CHIP RES. 1/10W F 220 Ω
R1612 RRXAFR5H2200 CHIP RES. 1/10W F 220 Ω
R1614 RCX6JATZ0223 CARBON RES. 1/6W J 22k
Ω
R1616 RRXAJR5Z0270 CHIP RES. 1/10W J 27 Ω
R1617 RCX4JATZ0301 CARBON RES. 1/4W J 300
Ω
R1618 RRXAJR5Z0361 CHIP RES. 1/10W J 360 Ω
R1619 RRXAJR5Z0392 CHIP RES. 1/10W J 3.9k Ω
R1620 RCX4JATZ0272 CARBON RES. 1/4W J
2.7k Ω
R1621 RCX4JATZ0272 CARBON RES. 1/4W J
2.7k Ω
R1622 RCX4JATZ0272 CARBON RES. 1/4W J
2.7k Ω
R1623 RRXAJR5Z0302 CHIP RES. 1/10W J 3k Ω
R1624 RRXAJR5Z0302 CHIP RES. 1/10W J 3k Ω
R1625 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R1626 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1628 RRXAJR5Z0100 CHIP RES. 1/10W J 10 Ω
R1629 RCX6JATZ0152 CARBON RES. 1/6W J
1.5k Ω
R1630 RCX4JATZ0102 CARBON RES. 1/4W J 1k
Ω
R1631 RCX4JATZ0221 CARBON RES. 1/4W J 220
Ω
R1632 RRXAFR5H3302 CHIP RES. 1/10W F 33.0k
Ω
R1633 C RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1634 RCX4JATZ0682 CARBON RES. 1/4W J
6.8k Ω
R1635 RCX4JATZ0682 CARBON RES. 1/4W J
6.8k Ω
R1636 RCX4JATZ0821 CARBON RES. 1/4W J 820
Ω
R1637 RCX6JATZ0152 CARBON RES. 1/6W J
1.5k Ω
R1638 RCX4JATZ0151 CARBON RES. 1/4W J 150
Ω
R1639 RCX6JATZ0331 CARBON RES. 1/6W J 330
Ω
R1640 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R1641 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R1642 RRXAJR5Z0102 CHIP RES. 1/10W J 1k
Ω
R1643 RCX4JATZ0181 CARBON RES. 1/4W J 180
Ω
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
R1645 RRXAJR5Z0332 CHIP RES. 1/10W J 3.3k Ω
R1646 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R1647 RRXAFR5H3302 CHIP RES. 1/10W F 33.0k
Ω
R1648 RCX4JATZ0181 CARBON RES. 1/4W J 180
Ω
R1649 RCX4JATZ0682 CARBON RES. 1/4W J
6.8k Ω
R1650 RRXAJR5Z0683 CHIP RES. 1/10W J 68k Ω
R1651 RRXAJR5Z0822 CHIP RES. 1/10W J 8.2k Ω
R1652 RRXAJR5Z0683 CHIP RES. 1/10W J 68k Ω
R1654 RRXAFR5H1000 CHIP RES. 1/10W F 100 Ω
R1655 RRXAFR5H1501 CHIP RES. 1/10W F 1.5k Ω
R1656 RCX4JATZ0561 CARBON RES. 1/4W J 560
Ω
R1657 RRXAFR5H4701 CHIP RES. 1/10W F 4.7k Ω
R1658 RRXAJR5Z0332 CHIP RES. 1/10W J 3.3k Ω
R1660 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1661 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1666 RCX4JATZ0100 CARBON RES. 1/4W J 10
Ω
R1667 RCX4JATZ0120 CARBON RES. 1/4W J 12
Ω
R1673 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1674 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1676 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1677 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1678 RRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R1679 RRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R1680 RRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R1681 RRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R1682 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1683 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1684 RRXAJR5Z0682 CHIP RES. 1/10W J 6.8k Ω
R1687 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1688 RRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R1689 RCX4JATZ0821 CARBON RES. 1/4W J 820
Ω
R1690 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1691 RRXAJR5Z0122 CHIP RES. 1/10W J 1.2k Ω
R1692 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1693 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1694 RRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R1695 RRXAFR5H8201 CHIP RES. 1/10W F 8.2k Ω
R1696 RRXAFR5H1302 CHIP RES. 1/10W F 13k Ω
R1697 RRXAJR5Z0133 CHIP RES. 1/10W J 13k Ω
R1698 RRXAFR5H8201 CHIP RES. 1/10W F 8.2k Ω
R1699 RRXAFR5H1302 CHIP RES. 1/10W F 13k Ω
R1700 RRXAJR5Z0133 CHIP RES. 1/10W J 13k Ω
R1701 RCX4JATZ0681 CARBON RES. 1/4W J 680
Ω
R1702 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1703 RRXAJR5Z0104 CHIP RES. 1/10W J 100k
Ω
R1704 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R1705 RRXAJR5Z0104 CHIP RES. 1/10W J 100k
Ω
R1706 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R1707 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1708 RCX4JATZ0750 CARBON RES. 1/4W J 75
Ω
R1709 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R1710 RCX6JATZ0332 CARBON RES. 1/6W J
3.3k Ω
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
