20070312 1-21-8 E3B90EL
R463 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R464 RRXAJR5Z0332 CHIP RES. 1/10W J 3.3k Ω
R465 RRXAJR5Z0562 CHIP RES. 1/10W J 5.6k Ω
R466 RRXAJR5Z0822 CHIP RES. 1/10W J 8.2k Ω
R469 RRXAJR5Z0223 CHIP RES. 1/10W J 22k Ω
R470 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R479 RRXAJR5Z0330 CHIP RES. 1/10W J 33 Ω
R480 RCX6JATZ0101 CARBON RES. 1/6W J 100
Ω
R481 RRXAJR5Z0330 CHIP RES. 1/10W J 33 Ω
R482 RRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R483 RRXAJR5Z0223 CHIP RES. 1/10W J 22k Ω
R484 RRXAJR5Z0682 CHIP RES. 1/10W J 6.8k Ω
R509 RRXAJR5Z0181 CHIP RES. 1/10W J 180 Ω
R511 RCX6GATZ0362 CARBON RES. 1/6W G
3.6k Ω
R512 RRXAJR5Z0683 CHIP RES. 1/10W J 68k Ω
R513 RRXAJR5Z0333 CHIP RES. 1/10W J 33k Ω
R514 RCX6GATZ0103 CARBON RES. 1/6W G
10k Ω
R516 RCX6GATZ0471 CARBON RES. 1/6W G
470 Ω
R517 RCX4JATZ0271 CARBON RES. 1/4W J 270
Ω
R519 RCX6GATZ0223 CARBON RES. 1/6W G
22k Ω
R523 RCX6GATZ0152 CARBON RES. 1/6W G
1.5k Ω
R525 RRXAJR5Z0394 CHIP RES. 1/10W J 390k
Ω
R526 RCX6JATZ0394 CARBON RES. 1/6W J
390k Ω
R528 RCX6GATZ0472 CARBON RES. 1/6W G
4.7k Ω
R536 RRXAJR5Z0182 CHIP RES. 1/10W J 1.8k Ω
R537 RRXAJR5Z0681 CHIP RES. 1/10W J 680 Ω
R539 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R540 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R541 RRXAJR5Z0183 CHIP RES. 1/10W J 18k Ω
R542 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R543 RCX4JATZ0102 CARBON RES. 1/4W J 1k
Ω
R544 RCX6JATZ0103 CARBON RES. 1/6W J 10k
Ω
R545 RCX6JATZ0103 CARBON RES. 1/6W J 10k
Ω
R546 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R555 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R567 RRXAJR5Z0393 CHIP RES. 1/10W J 39k Ω
R568 RRXAJR5Z0224 CHIP RES. 1/10W J 220k
Ω
R569 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R570 RCX6JATZ0472 CARBON RES. 1/6W J
4.7k Ω
R572 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R574 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R575 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R576 A,B RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R577 RRXAJR5Z0152 CHIP RES. 1/10W J 1.5k Ω
R578 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R582 RRXAJR5Z0104 CHIP RES. 1/10W J 100k
Ω
R585 RRXAJR5Z0473 CHIP RES. 1/10W J 47k
Ω
R586 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R588 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R592 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R595 RCX4JATZ0102 CARBON RES. 1/4W J 1k
Ω
R617 JW5.0T BOARD JUMPER D0.6-
P5.0
R618 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R621 RRXAJR5Z0683 CHIP RES. 1/10W J 68k Ω
R622 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
R623 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R624 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R625 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R626 RRXAJR5Z0182 CHIP RES. 1/10W J 1.8k Ω
R627 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R628 RRXAJR5Z0122 CHIP RES. 1/10W J 1.2k Ω
R629 RRXAJR5Z0152 CHIP RES. 1/10W J 1.5k Ω
R630 RRXAJR5Z0392 CHIP RES. 1/10W J 3.9k Ω
R631 RCX4JATZ0151 CARBON RES. 1/4W J 150
Ω
R648 RCX4JATZ0102 CARBON RES. 1/4W J 1k
Ω
R650 RCX4JATZ0102 CARBON RES. 1/4W J 1k
Ω
R653 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R656 RCX4JATZ0102 CARBON RES. 1/4W J 1k
Ω
R663 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R664 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R665 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1501 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1502 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R1504 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω
R1505 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1506 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1507 RRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R1508 RRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R1515 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω
R1531 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1534 RRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R1535 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1540 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω
R1543 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1544 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω
R1545 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1546 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1547 RRXAJR5Z0471 CHIP RES. 1/10W J 470 Ω
R1548 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω
R1549 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω
R1551 RRXAJR5Z0153 CHIP RES. 1/10W J 15k Ω
R1552 RRXAJR5Z0153 CHIP RES. 1/10W J 15k Ω
R1553 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1554 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1555 RRXAJR5Z0104 CHIP RES. 1/10W J 100k
Ω
R1558 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω
R1560 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω
R1564 RRXAJR5Z0474 CHIP RES. 1/10W J 470k
Ω
R1565 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1570 JW5.0T BOARD JUMPER D0.6-
P5.0
R1571 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1572 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1575 RRXAJR5Z0183 CHIP RES. 1/10W J 18k Ω
R1576 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1577 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω
R1578 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k
Ω
R1579 RRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω
R1580 RRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω
R1581 RRXAJR5Z0121 CHIP RES. 1/10W J 120 Ω
R1582 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0
Ω
R1584 RRXAJR5Z0621 CHIP RES. 1/10W J 620 Ω
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
