20070312 1-21-7 E3B90EL

Q406 NQ1YKTC3875S CHIP TRANSISTOR

KTC3875S-Y-RTK/P

Q451 NQ1ZKRC103SP TRANSISTOR KRC103S-

RTK/P

Q506 NPWZT2046B12 PHOTO TRANSISTOR

PT204-6B-12

Q514 NQSYKTA1267P TRANSISTOR KTA1267-Y-

AT / P

Q515 NQSZKRC106MP NPN TRANSISTOR

KRC106M-AT/P

Q520 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1502 NQSYKTC3203P TRANSISTOR KTC3203-Y-

AT / P

Q1503 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1504 NQSYKTA1267P TRANSISTOR KTA1267-Y-

AT / P

Q1505 NQSYKTA1267P TRANSISTOR KTA1267-Y-

AT / P

Q1508 NQVYKTA1281P TRANSISTOR KTA1281Y-

AT / P

Q1509 NQSZKRC103MP NPN TRANSISTOR

KRC103M-AT/P

Q1511 NQSZ0KRA104M RES. BUILT-IN

TRANSISTOR KRA104M-

AT / P

Q1512 NQSZKRC103MP NPN TRANSISTOR

KRC103M-AT/P

Q1513 NQSYKTC3198P TRANSISTOR KTC3198-Y-

AT / P

Q1514 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1515 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1516 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1517 NQSYKTC3203P TRANSISTOR KTC3203-Y-

AT / P

Q1518 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1519 NQSYKTC3203P TRANSISTOR KTC3203-Y-

AT / P

Q1520 NQSYKTC3203P TRANSISTOR KTC3203-Y-

AT / P

Q1521 NQSYKTC3203P TRANSISTOR KTC3203-Y-

AT / P

Q1525 NQSZKRC103MP NPN TRANSISTOR

KRC103M-AT/P

Q1526 NQS5KTC3199P TRANSISTOR KTC3199-

BL-AT/P

Q1527 NQSYKTA1267P TRANSISTOR KTA1267-Y-

AT / P

Q1528 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1529 QF1GSSM3K15F MOS FET

SSM3K15F(TE85L F)

Q1530 QF1GSSM3K15F MOS FET

SSM3K15F(TE85L F)

Q1531 NQSZKRC103MP NPN TRANSISTOR

KRC103M-AT/P

Q1532 NQSZKRC103MP NPN TRANSISTOR

KRC103M-AT/P

Q1533 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1534 NQSYKTA1267P TRANSISTOR KTA1267-Y-

AT / P

Q1535 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1536 NQS4KTA1266P TRANSISTOR KTA-1266-

GR-AT/P

Q1537 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1538 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1539 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1540 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1541 NQS4KTA1266P TRANSISTOR KTA-1266-

GR-AT/P

Loca-

tion No.

Mark TSB P/N Reference No. Description

Q1542 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1543 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1544 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1545 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

Q1546 NQSYKTC3199P TRANSISTOR KTC3199-Y-

AT / P

RESISTORS

R251 RRXAJR5Z0393 CHIP RES. 1/10W J 39k Ω

R252 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω

R301 RRXAJR5Z0122 CHIP RES. 1/10W J 1.2k Ω

R303 RRXAJR5Z0562 CHIP RES. 1/10W J 5.6k Ω

R305 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω

R308 A RRXAJR5Z0392 CHIP RES. 1/10W J 3.9k Ω

R312 A RRXAJR5Z0562 CHIP RES. 1/10W J 5.6k Ω

R314 RRXAJR5Z0392 CHIP RES. 1/10W J 3.9k Ω

R316 RRXAJR5Z0182 CHIP RES. 1/10W J 1.8k Ω

R319 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω

R320 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω

R321 RRXAJR5Z0151 CHIP RES. 1/10W J 150 Ω

R322 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω

R323 RRXAJR5Z0151 CHIP RES. 1/10W J 150 Ω

R325 RRXAJR5Z0122 CHIP RES. 1/10W J 1.2k Ω

R326 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω

R327 RRXAJR5Z0682 CHIP RES. 1/10W J 6.8k Ω

R328 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω

R329 RRXAJR5Z0221 CHIP RES. 1/10W J 220 Ω

R330 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω

R331 RRXAJR5Z0183 CHIP RES. 1/10W J 18k Ω

R332 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω

R333 RRXAJR5Z0183 CHIP RES. 1/10W J 18k Ω

R334 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω

R335 RRXAJR5Z0101 CHIP RES. 1/10W J 100 Ω

R336 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω

R337 RRXAJR5Z0682 CHIP RES. 1/10W J 6.8k Ω

R338 RRXAJR5Z0681 CHIP RES. 1/10W J 680 Ω

R370 C RRXAJR5Z0272 CHIP RES. 1/10W J 2.7k Ω

R371 C RCX6JATZ0562 CARBON RES. 1/6W J

5.6k Ω

R372 C RRXAJR5Z0392 CHIP RES. 1/10W J 3.9k Ω

R401 RCX4JATZ0821 CARBON RES. 1/4W J 820

R402 RCX6JATZ0101 CARBON RES. 1/6W J 100

R404 RRXAZR5Z0000 CHIP RES.(1608) 1/10W 0

R405 RRXAJR5Z0473 CHIP RES. 1/10W J 47k Ω

R406 RRXAJR5Z0223 CHIP RES. 1/10W J 22k Ω

R407 RRXAJR5Z0562 CHIP RES. 1/10W J 5.6k Ω

R408 RRXAJR5Z0123 CHIP RES. 1/10W J 12k Ω

R409 RRXAJR5Z0562 CHIP RES. 1/10W J 5.6k Ω

R410 RRXAJR5Z0102 CHIP RES. 1/10W J 1k Ω

R411 RRXAJR5Z0273 CHIP RES. 1/10W J 27k Ω

R412 RRXAJR5Z0121 CHIP RES. 1/10W J 120 Ω

R413 RRXAJR5Z0334 CHIP RES. 1/10W J 330k

R414 RRXAJR5Z0123 CHIP RES. 1/10W J 12k Ω

R415 RRXAJR5Z0182 CHIP RES. 1/10W J 1.8k Ω

R416 RRXAJR5Z0561 CHIP RES. 1/10W J 560 Ω

R417 RRXAJR5Z0222 CHIP RES. 1/10W J 2.2k Ω

R418 RRXAJR5Z0123 CHIP RES. 1/10W J 12k Ω

R419 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω

R420 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω

R421 RRXAJR5Z0472 CHIP RES. 1/10W J 4.7k Ω

R451 RRXAJR5Z0562 CHIP RES. 1/10W J 5.6k Ω

R452 RRXAJR5Z0223 CHIP RES. 1/10W J 22k Ω

R462 RRXAJR5Z0103 CHIP RES. 1/10W J 10k Ω

Loca-

tion No.

Mark TSB P/N Reference No. Description
