FLOW CHART NO.15
Hi-Fi audio can not be playbacked normally in the linear audio mode. (E-E mode is normal.)
Are the CN504, the connected cable and the parts
on periphery of playback amplifier normal?
Is there no dirt on the surface of ACE head assembly?
Is the audio signal supplied to Pin(5) of IC301?
Replace
IC301.
Is the audio signal outputted to Pin(11) of IC301?
Check the line between Pin(11) of
IC301 and Pin(80) of IC451, and
service it if defective.
Service and replace poor parts.
Readjust the height of the ACE head assembly.
Clean the surface of ACE head assembly.
Ye s
Ye s
Is the height of ACE head assembly appropriate?
Ye s
Replace the ACE head assembly.
Ye s
NoYe s
No
No
No
No
To Next Page
