20070312 1-21-5 E3B90EL
C1629 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C1630 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C1631 CE0KMASDL470 ELECTROLYTIC CAP.
47μF/6.3V M
C1632 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C1633 CE0KMASDL470 ELECTROLYTIC CAP.
47μF/6.3V M
C1634 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
C1635 CE1JMASDL1R0 ELECTROLYTIC CAP. 1μF/
50V M
C1636 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
C1637 CE1JMASDL1R0 ELECTROLYTIC CAP. 1μF/
50V M
C1638 CE1JMASDL1R0 ELECTROLYTIC CAP. 1μF/
50V M
C1639 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
C1640 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
C1641 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
C1642 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
C1643 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
C1644 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C1645 CE0KMASDL470 ELECTROLYTIC CAP.
47μF/6.3V M
C1646 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C1647 CE0KMASDL471 ELECTROLYTIC CAP.
470μF/6.3V M
C1648 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C1650 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C1653 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C1654 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C1655 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C1656 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C1657 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C1658 CHD1JK30B102 CHIP CERAMIC
CAP.(1608) B K 1000pF/
50V
C1659 CE1JMASDL1R0 ELECTROLYTIC CAP. 1
μF/
50V M
C1660 CHD1JJ3CH680 CHIP CERAMIC
CAP.(1608) CH J 68pF/50V
C1661 CHD1JK30B103 CHIP CERAMIC
CAP.(1608) B K 0.01μF/
50V
C1663 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C1665 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C1668 CE0KMASDL470 ELECTROLYTIC CAP.
47μF/6.3V M
C1673 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C1674 CHD1JK30B222 CHIP CERAMIC CAP. B K
2200pF/50V
C1675 CHD1JK30B102 CHIP CERAMIC
CAP.(1608) B K 1000pF/
50V
C1676 CE1JMASDL1R0 ELECTROLYTIC CAP. 1μF/
50V M
C1677 CHD1JK30B102 CHIP CERAMIC
CAP.(1608) B K 1000pF/
50V
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
C1678 CHD1JZ30F104 CHIP CERAMIC
CAP.(1608) F Z 0.1μF/50V
C1681 CE1JMASDL1R0 ELECTROLYTIC CAP. 1μF/
50V M
C1687 CHD1JZ30F103 CHIP CERAMIC CAP. F Z
0.01μF/50V
C1688 CE1JMASDL100 ELECTROLYTIC CAP.
10μF/50V M
C1689 CE1JMASDLR33 ELECTROLYTIC CAP.
0.33μF/50V M
C1690 JW5.0T BOARD JUMPER D0.6-
P5.0
C1694 CE1CMASDL101 ELECTROLYTIC CAP.
100μF/16V M
C1695 CE1CMASDL470 ELECTROLYTIC CAP.
47μF/16V M
C1696 CHD1JJ3CH680 CHIP CERAMIC
CAP.(1608) CH J 68pF/50V
C1697 CHD1JJ3CH680 CHIP CERAMIC
CAP.(1608) CH J 68pF/50V
C1699 CHD1JJ3CH330 CHIP CERAMIC
CAP.(1608) CH J 33pF/50V
C1702 CHD1JJ3CH680 CHIP CERAMIC
CAP.(1608) CH J 68pF/50V
CONNECTORS
CN1502 JC96J30ER007 FFC CONNECTOR 30PIN
IMSA-9615S-30A-PP-A
CN1503 JC96J30ER007 FFC CONNECTOR 30PIN
IMSA-9615S-30A-PP-A
CN1504 JCFNG20JG022 FMN CONNECTOR SIDE
20P 20FMN-STRK-
A(LF)(SN)
CN1507 A,B E3B01AFV AFV BOARD ASSEMBLY
E3B01BD
CN1507 C E3B02AFV AFV BOARD ASSEMBLY
E3B02FD
DIODES
D301 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D370 C QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D510 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D520 NPQZ0012541T LED(RED) 1254IT
D555 P000492990 QPQPS1R563ST LED SIR-563ST3F P
D1501 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1502 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1503 NDQZ001N4005 RECTIFIER DIODE
1N4005
D1505 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1506 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1507 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1512 NDQZ001N4005 RECTIFIER DIODE
1N4005
D1513 JW5.0T BOARD JUMPER D0.6-
P5.0
D1514 NDQZ001N4005 RECTIFIER DIODE
1N4005
D1515 NDQZ001N4005 RECTIFIER DIODE
1N4005
D1516 QDTZ001SS133 SWITCHING DIODE
1SS133(T-77)
D1517 QDTB00MTZJ33 ZENER DIODE MTZJT-
7733B
D1522 NDQZ001N4005 RECTIFIER DIODE
1N4005
D1523 NDQZ001N4005 RECTIFIER DIODE
1N4005
D1524 QDTB00MTZJ10 ZENER DIODE MTZJT-
7710B
D1525 QDTC0MTZJ5R6 ZENER DIODE MTZJT-
775.6C
D1526 QDTB00MTZJ18 ZENER DIODE MTZJT-
7718B
!
Loca-
tion No.
Mark TSB P/N Reference No. Description
To Next Page
