7. How to set the environment for OPC Server
85
Table 7.1 List of OPC items (simulation mode)
Prefix
Item Name
Description
Data Type
Mode
Tcnet
RasInfo.Mac#mmm.Stack#sA.OptPort#p.
NumOfPackets
HUB(#mmm) stack(#s) optical port(#p) Number of
received packets (A System)
[Stack: #0 - #3] [Port: #1 - #8]
VT_UI2 R(Sim)/W
RasInfo.Mac#mmm.Stack#sA.ElePort.
NumOfPackets
HUB(#mmm) stack(#s) Electrical port Number of
received packets (A System)
VT_UI2 R(Sim)/W
RasInfo.Mac#mmm.Stack#sB.OptPort#p.
NumOfPackets
HUB(#mmm) stack(#s) optical port(#p) Number of
received packets (B System)
VT_UI2 R(Sim)/W
RasInfo.Mac#mmm.Stack#sB.ElePort.
NumOfPackets
HUB(#mmm) stack(#s) Electrical port Number of
received packets (B System)
VT_UI2 R(Sim)/W
RasInfo.Mac#mmm.RasArea.HealthyCounter
Healthy counter of a RAS information area
VT_UI2
R(Sim)/W
TimeInf#d
Time information [#0 - #1]
VT_UI4
RO
Opc
LocalNodeAddr
Own node's address (node address on TC-net side)
VT_UI2
R/W(Sim)
LocalNodeStatus
Own node's state (ONLINE/STANDBY/BACKUP etc.)
VT_UI2
R/W(Sim)
ParentNodeAddr#d
Parent node's address for maximum 9 nodes [#0 - #8]
VT_UI2
R/W(Sim)
ParentNodeStatus#d
Parent node's state for maximum 9 nodes [#0 - #8]
VT_UI2
R/W(Sim)
ChildNodeAddr
Child node's address
VT_UI2
R/W(Sim)
ChildNodeStatus
Child node's state
VT_UI2
R/W(Sim)
BackupNodeAddr#d
Parent node's address during backing up for maximum 9
nodes [#0 - #8]
VT_UI2 R/W(Sim)
OperationTime
Running time
VT_UI4
RO
HealthyCounter
Healthy counter
VT_UI2
R(Sim)/W
DualControl
Control dual state
(=1 :
STANDBY request / =0 : STANDBY release
request)
VT_UI2 R/W
ScanTalkerStatus
Duplicate state of talker blocks
VT_UI2
R/W(Sim)
Client.HealthyCounter#mmm
Client Healthy Counter [#000 - #127]
= 1 - 65535 : check it
= 0 : not check
VT_UI2 R(Sim)/W
Client.Abnormal#mmm
Client diagnosis is abnormal [#000 - #127]
VT_ BOOL
R/W(Sim)
Client.AbnormalDetect
Client abnormal detection state
(AND of a diagnosis result for 128 clients)
VT_ BOOL R/W(Sim)
ParentTalkerStatus#d
Parent node's duplicate state of talker blocks [#0 - #8]
VT_UI2
R/W(Sim)
OpcSrv.MemUsed.Current
Quantity of memory use of OPC server (Current value)
VT_UI4
RO
OpcSrv.MemUsed.Average
Quantity of memory use of OPC server (Average value)
VT_UI4
RO
* In an item of "RasInfo.Mac#mmm", Start/Stop increment of Simulation data is done every station collectively.
