5.5.9 Output Relay Programming Features
Notes:
Check wiring to each relay before changing programming to ensure there
are no unintended consequences.
Relays programmed to some protection features will not operate if
function is disabled elsewhere.
5.5.10 Serial Communications
Fn # Group Function Description Adjustment / Display Range
Setting
Increments
Factory
Setting
Section
F060
Output Relays
Aux Relay 1 setting
Operation # 1 – 26: see
”Aux. Relay Settings Chart”
1 1
5.6.9
F061 Aux Relay 2 setting
Operation # 1 – 26: see
”Aux. Relay Settings Chart”
1 2
F062 Aux Relay 3 setting
Operation # 1 – 26: see
”Aux. Relay Settings Chart”
1 16
F063
Aux. Relay Delay Timer
(for Operations 23-26)
0 (Disabled), or 1-999 seconds 1 second
0
No Delay
F064 Reserved for factory use
Table 5.5.9: Output Relay Function Group
Fn # Group Function Description Adjustment / Display Range
Setting
Increments
Factory
Setting
Section
F065
Communications
Communications
0 = Disabled
1 = Enabled (11Bit)
2 = Enabled (10Bit)
1 0
5.6.10
F066 Baud Rate 4.8, 9.6 and 19.2 KB 3 rates 9.6 KB
F067 Modbus Address 1 - 247 1 1
F068 Remote Starter Control
0 = Disabled
1 = Enabled w/ Start button
2 = Enabled w/o Start button
3 = Enabled via Jog-Remote Input
1 0
F069 Reserved for factory use
Table 5.5.10: Serial Communications Function Group
