5.6.9 Output Relays
There are three programmable relays (rated 240VAC, 5A, 1200 VA) in
the TE Series. They can be programmed for change of state indication
for any one of the 25 conditions identified in the following chart.
F060 = Aux Relay 1: Form C (SPDT)
Factory Setting = 1 (Run / Stop)
Range = 1 - 27 (See list)
Use to program the desired operation for Relay # 1.
F061 = Aux Relay 2: Form C (SPDT)
Factory Setting = 2 (At-Speed / Stop)
Range = 1 - 27 (See list)
Use to program the desired operation for Relay # 2.
F062 = Aux Relay 3: Form A (SPST, N.O.)
Factory Setting = 16 (Any Trip, 5 - 15)
Range = 1 - 27 (See list)
Use to program the desired operation for Relay # 3.
F063 = Aux Relay Delay Timer for Settings 23 – 26
Factory Setting = 0 (Disabled)
Range = 1 – 999 seconds, or 0 (Disabled)
Use to program the desired On Delay for any Aux. Relay that
has been programmed for Settings 23 through 26 from the chart
below.
F064 = Reserved
Setting Relay Operation Description
1 Run / Stop (Changes on Start Command, resets on Stop)
2 At-Speed / Stop
3 At-Speed / End of Decel
4 Start / End of Decel
5 Short SCR Trip
6 Phase Loss Trip
7 Shunt Trip
8 OL (Motor Thermal Overload) Trip
9 OT (Starter Thermal Over Temperature) Trip
10 Short Circuit Trip
11 Current Imbalance Trip
12 Over Current (Shear-Pin) Trip
13 Under Current Trip
14 Ground Fault Trip
15 Phase Rotation Trip
16 Any Trip (#5 - #15)
17 Any Trip, (#5-#15) flashing output*
18 Coast Down Time Lockout
19 Starts Per Hour Lockout
20 Time Between Starts Lockout
21 Any Lockout (#18-#20)
22 Run Timer (F030) Engaged
23 Run / Stop with On-delay from F063
24 At-Speed / Stop with On-delay from F063
25 At-Speed / End of Decel with On-delay from F063
26 Start / End of Decel with On-delay from F063
27 Power Loss (nCP No Control Power) Trip
*Note: Flash rate for Setting #17 is ½ second On and Off
Table 5.6.9: Output Relay Programming
