Appendix 5 (cont.) Soft Starter Settings Record
Fn # Group Function Description Adjustment / Display Range
Setting
Increments
Factory
Setting
Setting
F085
Fault History and Run Data
Fault History #1, Latest Fault
0 = No fault history, or
Fault # 1 - 27: see Fault code list
1 0
F086
Time Stamp, Fault #1
Based on F078-80
00.00-23.59 (hh.mm)
[hh = 00-23; mm = 00-59]
00.01 00.00
F087
Date Stamp, Fault #1
Based on F076-77
01.01 – 12.31 (MM.DD)
[MM = 01-12; DD = 01-31]
00.01 01.01
F088
Fault History #2, Previous
Fault
0 = No fault history, or
Fault # 1 - 27: see Fault code list
1 0
F089 Time Stamp, Fault #2
00.00-23.59 (hh.mm)
[hh = 00-23; mm = 00-59]
00.01 00.00
F090 Date Stamp, Fault #2
01.01 – 12.31 (MM.DD)
[MM = 01-12; DD = 01-31]
00.01 01.01
F091 Fault History #3, Oldest Fault
0 = No fault history, or
Fault # 1 - 27: see Fault code list
1 0
F092 Time Stamp, Fault #3
00.00-23.59 (hh.mm)
[hh = 00-23; mm = 00-59]
00.01 00.00
F093 Date Stamp, Fault #3
01.01 – 12.31 (MM.DD)
[MM = 01-12; DD = 01-31]
00.01 01.01
F094 Run Time, Hours 000.0 – 999.9 hours 0.1 hours 0
F095
Run Time,
1000 Hour Overflow
0000 – 9999 thousand hours 1 k-hour 0
F096 Run Cycle Counter 0000 – 9999 times 1 times 0
F097
Run Cycle Counter
10K overflow
0000 – 9999 10 thousand times
1 10k
times
0
