The Engineering System
Engineering tools can be classified into two types: the control station control logic
construction/maintenance tools and the process tag construction tools for the TOSDIC-CIE DS monitor
system, as shown in the tool system in Figure 2.1.
TOSDIC-CIE DS
Engineering Tool
Station Registration
Station Registration
Control System Tools
PCS-DS Construction
OIS/SVR Construction
DPCS Internal Logic
Construction
DPCS Construction
(Tag Registration)
Monitor System Tools
PCS-DS Engineering Tools
DPCS Builder
OIS-DS Engineering Tools
Files (FD) are passed
RAS/Maintenance
SVP Tool
Virtual I/O input Tool
Figure 2.1 The TOSDIC-CIE DS Engineering Tool System
To connect DPCS to TOSDIC-CIE DS, reconstruct the system by using the following development tools.
Table 2.1 shows overview of the functions of the Engineering Tools.
Table 2.1 DPCS Functions of Engineering Tools
Tool Name Item Description
OIS/SVR
Engineering Tool
DPCS Station
Registration
Registers the DPCS Station Type to the TOSDIC-CIE DS
system.
PCS-DS
Engineering Tool
DPCS Station/Card
Configuration Registration
Registers the DPCS Station Type and the control card
configuration in DPCS
Process Tag Configuration Registers DPCS tag names, I/O points, and parameters.
DPCS-to-DPCS
Transmission Registration
Registers the send data definition for data transmission
between DPCS’s or PCS-DS’s and the receive data.
Real Time Trend
Information Registration
Registers the trend data recorded in the DPCS.
Serial I/O Registration Registers the Serial I/O configuration.
DPCS I/O Mapping Registers DPCS I/O points to Serial I/O points.
System Log Display System, Application Log.
SIO Log Display Serial I/O Log.
SVP Tool SVP function The function of SVP. Display the data and the parameter
in each DPCS control card
Virtual I/O input
Tool
Input data from Tool The input data from I/O module is carried out by the input
of Virtual I/O input Tool
DPCS Builder Controller Function
Construction
Creates/modifies the DPCS Control Logic.
