Appendix 1. Ethernet Control LAN Network Construction Guide
24
System Specifications
Table A1.1 Ethernet Control LAN Transmission Line Specifications
Item Specification
Complied Standards IEEE 802.3
- 10BASE5
- 10BASE-T
- FOIRL
Transmission Configuration Bus Type
Transmission Speed 10Mbps
Medium Access Method CSMA/CD
Transmission Signal Base Band
Transmission Line Length Maximum 2.5km
No. of Connected Stations Maximum 32 stations/system
Transmission Line Length Maximum 2.5km (when repeaters are used)
10BASE5 :500m/segment
10BASE-T :100m/segment
FOIRL :1000m/segment
Transmission Cable 10BASE5 :Coaxial Cable (so-called Yellow Cable, 50)
AUI Cable (Transceiver Cable)
10BASE-T :Twisted Pair Cable
FOIRL :Optical Cable (GI 50/125 two-wire)
Station Spacing 2.5 meters on a 10BASE5 coaxial cable
Connector Shape 10BASE5 :N-type
10BASE-T :Modular Plug
FOIRL :FC-type or ST type
Grounding Type-3 Grounding Process (One-point Grounding)
Transmission Line
Redundancy
Standard
Network Device Power
Supply Specifications
- Hub (MPR-855T)
Power Supply Voltage : AC90110V(50/60Hz)
Power Consumption : 17W or less
- Optical Repeater (MPR-410/T)
Power Supply Voltage : AC85130V(50/60Hz)
Power Consumption : 75W or less
- Electric Repeater (MPR-410/T-E)
Power Supply Voltage : AC85130V(50/60Hz)
Power Consumption : 75W or less
