Toshiba Tosvert VF-S15 Function Manual

E6582051
- 21 -
4.1.3. Communication parameters for VF-S15/AS3/MB1
Title
Communica
tion No.
Function Description
Default
setting
c081-
c096
C081-
C096
Device Name 1-16 (*1)
Max 16 characters
The device name is required if the card uses
DHCP to obtain its IP Address.
0
c100
C100
Communication error detection
delay time
0.0 - 100.0 sec.
The waiting time of network error detection can be
adjusted. If a network error continues past the time
set in
c100
, it is recognized as a communication
error, and inverter will operate according the setting
of
c101
. If network error was removed during
c100
, inverter will continue normal operation.
0.0
c101
C101
Inverter operation at the
communication loss action
0: Stop and controlled by
cmod
,
fmod
1: Operation continue
2: Deceleration stop
3: Coast stop
4: Network error stop (
err8
trip)
5: Preset speed operation (by
c102
setting)
4
c102
C102
Preset speed operation
selection
0: None
1 to 15: Preset speed
The operation frequency when the communication
fault is occurred can be selected from preset
speed. (Only when
c101
is set to 5)
0
c103
C103
Communication error condition
selection
0: Always
1: Communication command (Frequency
reference and command from communication
option) enabled
2: 1+during run
1
c154
C154
PROFIdrive JOG1 frequency 0.0 to 20.0Hz 5.0Hz
c155
C155
PROFIdrive JOG2 frequency 0.0 to 20.0Hz 5.0Hz
c156
C156
PROFIdrive Tmax
0.1 to 60.0s 10.0s
c157
C157
PROFIdrive Tolerance 0.1 to 99.0% 50.0%
c504
C504
IP mode (*2)
Use this parameter to select the IP address
assignment method.
0: Manual
1:Invalid setting
2: DHCP
3: DCP
0
c505-
c508
C505-
C508
IP address setting value (*2)
The IP address of the option module.
These fields are effective settings at
c504
= 0.
0.0.0.0
c509-
c512
C509-
C512
Subnet mask setting value (*2)
The subnet mask of the option module.
These fields are effective settings at
c504
= 0.
0.0.0.0
c513-
c516
C513-
C516
Default gateway setting value
(*2)
The gateway IP address of the option module.
These fields are effective settings at
c504
= 0.
0.0.0.0
c554
C554 Web server (*2)
Enables web server.
0: Disable
1: Enable
1
(*1): (
typ
) does not work for this parameter.
(*2): These parameters are affected after reset.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
