5. PROFIdrive Profile
Transmission frame of each Telegram of this product is configured as shown below.
PKW: Parameter ID/value
PZD: Process Data, cyclically transferred
5.1.
Telegram 1: PROFIdrive
PROFIdrive standard
This telegram complies with PROFIdrive standard
Notes
When you use this telegram, the value is written to the RAM.
PLC → INV INV → PLC
C
y
clic data 1 STW ZSW
C
y
clic data 2 HSW HIW
INV: Inverter
STW: Control word
HSW: Main setpoint
ZSW: Status word
HIW: Main actual value
PKW PZD
PKW1 PKW2 PKW3 PKW4
Cyclic
data1
Cyclic
data2
Cyclic
data3
Cyclic
data4
Cyclic
data5
Cyclic
data6
Cyclic
data1
Cyclic
data2
PKW1 PKW2 PKW3 PKW4
Cyclic
data1
Cyclic
data2
PKW1 PKW2 PKW3 PKW4
Cyclic
data1
Cyclic
data2
Cyclic
data3
Cyclic
data4
Cyclic
data5
Cyclic
data6
Telegram 1
Telegram 100
Telegram 101
Cyclic
data1
Cyclic
data2
Cyclic
data3
Cyclic
data4
Cyclic
data5
Cyclic
data6
Telegram 102
