Toshiba Tosvert VF-S15 - Telegram 100: Vendor Specific; Telegram 101: Vendor Specific

E6582051
- 35 -
6.1. Telegram 100: Vendor specific
The parameter access via PKW, and the transmission of two commands and monitors via cyclic data are
supported by Telegram 100.
6.2. Telegram 101: Vendor specific
The parameter access via PKW, and the transmission of six commands and monitors via cyclic data are
supported by Telegram 101.
PLC → INV INV → PLC
PKW1 PKW1
(
PKE
)
PKW1
(
PKE
)
PKW2 PKW2
(
IND
)
PKW2
(
IND
)
PKW3 PKW3
(
PWE1
)
PKW3
(
PWE1
)
PKW4 PKW4
(
PWE2
)
PKW4
(
PWE2
)
C
y
clic data 1
c001 c021
C
y
clic data 2
c002 c022
INV: Inverter
PKW: Parameter ID/value
PKE: Parameter ID (1st and 2nd octet)
IND: Sub-index (3rd octet),
4th octet is reserved
PWE: Parameter value (5th until 8th octet)
PLC → INV INV → PLC
PKW1 PKW1
(
PKE
)
PKW1
(
PKE
)
PKW2 PKW2
(
IND
)
PKW2
(
IND
)
PKW3 PKW3
(
PWE1
)
PKW3
(
PWE1
)
PKW4 PKW4
(
PWE2
)
PKW4
(
PWE2
)
C
y
clic data 1
c001 c021
C
y
clic data 2
c002 c022
C
y
clic data 3
c003 c023
C
y
clic data 4
c004 c024
C
y
clic data 5
c005 c025
C
y
clic data 6
c006 c026
INV: Inverter
PKW: Parameter ID/value
PKE: Parameter ID (1st and 2nd octet)
IND: Sub-index (3rd octet),
4th octet is reserved
PWE: Parameter value (5th until 8th octet)
