Toshiba Tosvert VF-S15 Function Manual

E6582051
- 24 -
4.2.3. Relation common parameters for VF-S15/AS3/MB1
Title
Communi
cation No.
Function Description
c152
C152
PROFIdrive Profile monitor
0：Telegram 1 (PROFIdrive)
1：Telegram 100 (Vender Spec. 1)
2：Telegram 101 (Vender Spec. 2)
3
：
Telegram 102 (Vender Spec. 3)
c517-
c522
C517-
C522
MAC address monitor (*1)
The MAC address of the option module.
[
c517
-
c518
-
c519
-
c520
-
c521
-
c522
]
c524-
c527
C524-
C527
IP address monitor
The current IP address of the option module.
c528-
c531
C528-
C531
Subnet mask monitor
The subnet mask actual of the option module.
Refer to "4.3.2 Assigning IP addresses" for the
details.
c532-
c535
C532-
C535
Default gateway monitor
The gateway IP address actual of the option
module.
Refer to "4.3.2 Assigning IP addresses" for the
details.
c536
C536 Ethernet Error monitor
Monitor of the Ethernet error.
0: No error
1: PROFINET I/O timeout
2: Network overload
3: Loss of Ethernet carrier
9: duplicated IP address.
10: No valid IP.
17: Application I/O configuration error
(*1): These values are displayed by decimal number format on panel of VFS15/AS3/MB1.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
